|Automatic Grade:||Fully Automatic||Place Of Original:||Shandong , China|
|Screw&Barrel Material:||38Cr MOAIA||Payment Terms:||TT Or L/C|
Board Production Line,
Panel Production Line
3-25mm 1220mm WPC Construction Template Production Line / WPC Furniture Board Making Machine
1. WPC building templates are extruded through high temperature, high pressure and melt based on the material of PVC and wood fiber powder and some chemical auxiliary additives.
Main material;PVC+wood poeder
This products is mainly used for extruding construction template,furniture board.
WPC building templates are very suitable for high-building standard template, shear wall, vertical wall plate, bridge, dam and tunnel templates and so on.
2.The System configuration of wpc construction templates production line
1. The main twin screw extruder
2. WPC door board mould
3. Vacuum Calibrating Platform
4. Haul Off Machine
5. Cutting Machine
7. Auxiliary parts: High Speed Cooling Mixer and Plastic Crusher
1. Process flow of wpc construction templates production line
Raw material + Wood powder + Additive → Mixing → Granules → Conical twin screw extruder → Profile extrusion mould → Cooling molding die → Vacuum calibrating table → Haul off → Cutter → Tilting stacker→Finished products inspecting and packing
2. PVC Foam Board Production Line is made and designed by our company through many years experience involving in manufacutrring PVC free foamed board production line and PVC Crust Foamed Board Production Line .PVC Foamed Board Prodcution Line has such characteristics as high surface hardness / good smoothness ,etc .
Industrial application: rot proof project in chemical industry, thermal shaped part, plate for refrigeratory warehouse, special cool-keeping project, environmental protection plate.
Other applaication: construction mold plate, sports apparatus, seashore wet-proof facility, water resistant material, arts material and all sorts of light separation plate
|Material||PVC + wood powder, with accessory material|
|Specification||Width 1220. Length 2440,|
|production line speed||1.5-3m/min|
|Outline size||23×2.5×3 L×W×H(m) unsaturation|
|air pressure||> 0.6Mpa|
|Water source||Industrial water, no impurity, with filtration treatment, pressure:0.4Mpa, temperature: 14-25°C|
|Working environment temperature||0-40°C|
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
Contact Person: AORUI
