Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface

Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface
Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface

Large Image :  Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface

Product Details:
Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month

Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface

Description
Raw Material: HIPS,ABS HS Code: 8477800000
Process: Plastic Extruder Market: Europe,america,africa,asia,etc...
Type: Sheet Plastic Production Line Screw Design: Single Screw
Field: Decoration Application: Package,protection,etc
Feature: Good Quality Color: According To Customer's Requirement
High Light:

plastic sheet extrusion machine

,

plastic sheet production line

Decorative Plastic Sheet Extrusion Line Single Screw with Bright surface


QUICK DETAIL :

1. Worm wheel to adjust the pressing roller
2. Bright surface of the pressing rollers
3. Equal temperature of the roller surface
4. Clean, bright, equal thickness sheet produced,
5. Select different plastic to produce the compound sheet with different colors according to different products.






Description:
   Plastic pellets are fed into the barrel of the extruder and conveyed by the screw, the heaters which are outside of the barrel of the extruder as well as the friction from the rotation of the screw melt the plastic pellets into a sheet mold and then placed on a three-roll calender, the produced sheet goes through the bottom and middle roll,wrapping around back of the middle roll and then back to the top roll or other methods as shown in sheet calender picture, these rolls are helpful to take the heat out of the sheet, after the sheet comes off the roll,it moves down the conveyor to the end of sheet line where the edge trimmer cuts the sheet to width as well as a sheet shear cutter to length.



Sheet Machinery Parameter of PP/PE Plastic Sheet Extrusion Machine

Layer Structure

Mono Layer Extrusion Line

3-layer Extrusion Line

5-layer Extrusion Line

Extruder Model

SJ90,SJ100,SJ120,SJ150,SJ200

SJ120/33,SJ65/33

SJ120/33,SJ45/33,SJ65/33

Sheet Width

600-1300MM

600-1300MM

600-1300MM

Sheet Thickness

0.25-2.0

0.3-2.0

0.3-2.0

Max.Capacity

150-500

250-400

250-450






FEATURES:



1. Width: 320-3000mm
2. Thickness: 0.2--2mm

3. Mono-layer and multi-layer sheet extrusion system for up to 5 layers

4. Processing capabilities: PE, PP, PS and other thermoplastic materials





Applications:



1.  Design with high technology, ensure high precision and high quality.

2.  Extruder screw with latest technology, ensure not only high extrusion output and  100% plasticization but also high gloss for finished cable

3.   Electric appliances all imported, ensure high running stability and service long life

4.   Japan RKC temperature control, improve high precision

5.   Gearbox of chromed steel alloy with high-cycle rigidifying and carefully grinding treatment to against abrasion and noise

6.   All electric elements are imported, ensure high running stability and long life







Specifications:



  Model

Unit

TYJB-75

TYJB-90

TYJB-110

  Material applied

PP,PS,PE

  Width of sheet

mm

≤600

≤750

≤1100

  Thickness of sheet

mm

0.2-1.6

0.2-2.0

0.2-2.0

  Extrusion capacity

kg/h

60-100

100-150

150-200

  Diameter of screw

mm

75

90

105

  Installed capacity

kw

75

90

120



Competitive Advantage:


1. Certification:CE,ISO,CNAS
2. Good formed effect
3. Available material:PP,HIPS,GPPS,PE
4. plastic sheet extruder
