Plastic Sheet Extrusion Line
Created with Pixso.

PP / PE Printing Plastic Sheet Extrusion Line , Recycled Plastic Sheet Production Line

PP / PE Printing Plastic Sheet Extrusion Line , Recycled Plastic Sheet Production Line

Brand Name: AORUI
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Width:
600-1200mm
Thickness:
0.2-1.2mm
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

plastic sheet extrusion machine

,

plastic sheet production line

Product Description

PP / PE Printing Sheet Plastic Extrusion Line , Recycled Plastic Sheet Production Line









QUICK DETAIL :



  Material : pp/pe

  Weight: 8 T

  Voltage: 380v/50hz

  Width: 600-1200mm

  Thickness: 0.2-1.2mm

  Screw dimamter: 65-90mm

   Screw design : single screw

  Certification : ce ul csa

  Condition : new

  Main motor power: 37-75KW

  After-sales Service Provided :  Engineers available to service machinery overseas





Description:



1.The specially designed screws ensure high plastification rate.


2.Precise temperature control(-1`C or +1`C) and special modules ensure precise thickness and flatness

control.


3.The thickness of sheet is precisely adjusted by adjusting the screws and oil pressure wheels.


4.The winder can automatically adjust the speed and tension and set the width of needed products freely.


5.The machine equipped with meter counter can set the length of product.





Applications:



Electronics,  food stuff package, building materials, decoration and daily necessities.

PP / PE Printing Plastic Sheet Extrusion Line , Recycled Plastic Sheet Production Line 0



Specifications:



  Model

Unit

TYJB-75

TYJB-90

TYJB-110

  Material applied

PP,PS,PE

  Width of sheet

mm

≤600

≤750

≤1100

  Thickness of sheet

mm

0.2-1.6

0.2-2.0

0.2-2.0

  Extrusion capacity

kg/h

60-100

100-150

150-200

  Diameter of screw

mm

75

90

105

  Installed capacity

kw

75

90

120





Competitive Advantage:



1.high output


2.energy saving


3.good plasticity


4.long working time
