Product Details:
|
| Brand Name: | Aorui | Place Ofo Riginal: | Shandong , China |
|---|---|---|---|
| Certificate: | CE ISO9001 | Screw Number: | Two |
| Temperature Controller: | Omron | Automatic Grade: | Fully Automatic |
| High Light: | wpc profile extrusion line,wood plastic machine |
||
One Step Profile Making WPC Panel Production Line , Two Screw Extruder
Quick detail:
WPC indoor and outdoor profile line
The production line is designed for extrusion of PVC plastic door`s and window`s profile and cross-section cable pipes, aluminum-plastic composite profiles etc. PVC profiles are widely used in the building industry, home, and office decoration.
With special designed screw, barrel. Moule and producing process, equipped with YF series downstream equipment, this line can produce PE PP PVV and wood powder profile. This is a new kind of environmental freindly building material. Mixing the plastic, wood powder, foam agent and other additives. After high temperature and high pressure extrusion, the products can be used for pallets, packing plates, windows and door frames, decoration panels and etc.
Description:
Details of WPC profile making machine
1. The machine is used to produce PVC wood plastic composite products, PVC profile etc;
2. Applied materials: PVC+wood powder, PVC powder material;
3. Features and advantages:
(1) It could produce PE, PP, PVC wood plastic profile, high additive amount of wood powder & plant fiber (max 50-75), strong adaptability, could process PE, PP, ABS, PS etc at the same time;
(2) This is our company's technique-matured machine model, we could supply overall technical support from aspects like raw materials recipe, production technology, mould forming etc.
Specifications:
|
Equipment Type |
Output(KG/H) |
Total Power (KW) |
L/D Ratio |
Screw Rotary Speed(R/Min) |
Outline Dimension (MM) |
Total Weight (KG) |
| SWMSY-1 | 40-60 | 71 | 10-32 | 30-80 | 11000*1050*2400 | 4900 |
| SWMSY-2 | 70-150 | 115.5 | 10-32 | 30-80 | 19300*2000*2900 | 7000 |
| SWMSY-3 | 90-180 | 143 | 10-32 | 30-80 | 20000*2200*3100 | 8000 |
Competitive Advantage:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
