Plastic PET PP Strap Band Extrusion Process / Strap Production Line Fully automatic

China Plastic PET PP Strap Band Extrusion Process / Strap Production Line Fully automatic supplier

Large Image :  Plastic PET PP Strap Band Extrusion Process / Strap Production Line Fully automatic

Product Details:

Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA
Model Number: PET90

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detailed Product Description
Brand Name: Aorui Condition: New
Automatic Grade: Fully Automatic Plastic Processed: PET
Warranty: 1 Year Certificate: CE ISO9001
After-sales Service: Engineers Availiable To Service Voltage: Acoording To Customer's Requirement

Plastic Strapping Band Machine / PET PP Strap Band Extrusion Process / PET Strap Production Line







Quick detail:



1. With 100% bottle flakes recycled material, to produce various specifications of PET strap. It consists of dehumidifying and crystallizing system, extruder, screen changer, mould, oven, haul-off, and winder, etc.



2. PET packing strap is widely used, replaced for steel strap for packing application internationally, because of its good tensile strength, flexible, low prolongation rate, good performance of high temperature resistant, non-rustiness, and low use-cost, etc, it is used in steel, construction material, chemical fiber, paper making, tobacco, agriculture, election, etc.







Description:



1. Thickness range: PET strap band is widely used on packing industry.
Width of Strap Band:9-32mm
Thickness range: 0.5-1.3m



2. The screw is specially designed for PET application, it consists of separate and mixing part to keep the even plastication, also by fixed material feeding system, the extrusion is stable, which ensures the good dimension of PET strap.



3. Production process:
Material loading---extruding--water cooling--hauling off---heating---hauling off---embossing---calibrating---hauling off---winding



4. Main machines:
Screw extruder--Die head and mould(two strips)---Cooling water tank---First haul-off---Thermal oven---Second haul-off---Embosser---calibrating---haul off-winder







Technological parameter:



Model SJ-65 SJ-75 SJ-90
Extruder SJ-65/30 SJ-75/33 SJ-90/33
Productivity 60-100kg/h 80-120kg/h 120-150kg/h
Drive Motor 22kw 30kw 55kw
Two-station Winder 60-120m/min,adjustable
Strap Size Width:5mm-20mm Width:10mm-25mm Width:20mm-35mm
Thickness:0.36mm-1.0mm Thickness:0.5mm-1.3mm Thickness:0.5mm-1.8mm
Installed Capacity about80kw about 90kw about110kw
Line Dimension 30m×2m×2.2m (L×W×H) 30m×3m×4.5m (L×W×H) 30m×5m×6m (L×W×











Our company competitive advantages:



1) We give you suitable suggestions according to your actual need.

2)experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology.



3) Provide on-site installation guide; Responsible for the commissioning of equipment; Responsible for the buyer's personnel mount guard before the operation and maintenance training;
