Product Details:
|
| Brand Name: | Aorui | Raw Material: | PP PE |
|---|---|---|---|
| Motor: | Siemens | Screw Design: | Single Screw |
| Voltage: | 380V 50HZ | After-sales Service: | Engineers Availiable To Service |
| Place Of Original: | Shandong , China | Frequency Control: | ABB |
| High Light: | Strapping Band Making Machine,Strap Making Machine |
||
High Performance PET Strap Band Making Machine , PET Strap Band Extrusion Line , Packing Belt EWxtrusion Process
Quick detail:
1. PET packing strap band extrusion line machine ,based on recycled PET bottle flake as the main raw materials,can produce many specifications,multi-purpose,high performance package strap.
2. PET strap machine can use Microcomputer control system,and auto feeding system,preheating dry system automatic circular,accurate and energy-effcient temperature control system,give a power-saving and low-noise system,reached a low-input,high-output purposes.
Description:
1.Adopts advanced CSW-800 comby dehumidify dryer system. It make sure the material humidity at 80PPM at 50PPM dew point. Meanwhile, it compact material and increase the viscidity.
2.Adopts closed cycle transport system after dryer to avoid contact with outside air and make sure the material be dry continuously.
3.Extruder adopts special screw for PET. The screw has unique separate and mix property to make sure uniform plasticizing. The screw suitable for recycled PET bottle flakes, PET mixture and original PET material. And the extruder adopts ration forced feeding to make sure the stable extruding. It makes sure the product uniform.
4.Produce different model product at one die and mould. Adopts automatic hydraulic screen exchanger .
5.Static cooling roller replace the water cooling tank. The roller will cool the strap at the constant temperature. It improves the product's stretch intensity.
6.The strap after formed will be warm and anneal treated to wipe off the part stress remained after stretch. It makes molecule tropism be steady to avoid strap distortion caused by storage.
7.The winder adopts double work position and auto-meter. It is easy operation and convenient coil change.
Centralized electrical control, PLC self-correcting control. Easy operation.
Technological parameter:
| Model | SJ-65 | SJ-75 | SJ-90 |
| Extruder | SJ-65/30 | SJ-75/33 | SJ-90/33 |
| Productivity | 60-100kg/h | 80-120kg/h | 120-150kg/h |
| Drive Motor | 22kw | 30kw | 55kw |
| Two-station Winder | 60-120m/min,adjustable | ||
| Strap Size | Width:5mm-20mm | Width:10mm-25mm | Width:20mm-35mm |
| Thickness:0.36mm-1.0mm | Thickness:0.5mm-1.3mm | Thickness:0.5mm-1.8mm | |
| Installed Capacity | about80kw | about 90kw | about110kw |
| Line Dimension | 30m×2m×2.2m (L×W×H) | 30m×3m×4.5m (L×W×H) | 30m×5m×6m (L×W× |
Technical and after-sales service:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
