Product Details:
|
| Brand Name: | Aorui | Plastic Processed: | PVC PP PE |
|---|---|---|---|
| Certificate: | CE ISO9001 | After-sales Service: | Engineers Availiable To Service |
| Application: | Plastic Profile | Model Number: | SJ65/33 |
| Motor: | Siemens | Automatic Grade: | Fully Automatic |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Extruder |
||
PVC WPC PP PE Window Wall Flooring Frame Extrusion Line , Plastic PP PE Profile Making Machinery , Profile Machine
Quick detail:
1. WPC Decking Profile Extrusion Line Wood Plastic Profile Making Machine. The PVC WPC profile production line could produce PVC window profile, door frame, board, ceiling, etc. This machine also could produce wood plastic profile ( WPC).
2. High quality, good price and reliable performance. Please don't be hesitate to contact us for more details. And we also warmly welcome you to visit our factory.
Specification of pvc wpc Profile Machine:
1. The PVC Profile production line includes the below machines;
1). Conical Twin Screw Extruder
2). Extrusion Mold ( The buyer shall prepare the drawing to make the mold)
3). Vacuum Calibration Table
4). Haul Off and Cutter
5). Stacker
6). PVC Mixer ( for raw material preparation)
7). Crusher and Milling Machine ( for recycle the waste and could reuse for profile production)
2. WPC extrison line: It adopts special design of screw & barrel, mould and extruder for wood plastic products.Aorui company products series:One step way thick board extrusion line,One step way WPC profile extrusion line;WPC pelletizing extrusion line and different kinds of WPC mould.
3. The WPC products can be produced by two step extrusion machine, or pelletzing first then through extrison machine, it will savepower and place,it has some feature: high output,stable extrusion pressure,high plastication, and good mixing. Optimized screwdesign have small cutting strength, and it is not easy to cut wood fibre, good plastication.
4. This extrusion line can produce PE,PP or PVC WPC profile products,Main application is for wood tray, indoors and outdoors floor,and outside decoration,and so on.
Technical Parameters:
| Items | YF180 | YF240 | YF300 | YF600 | YF900 |
| Max.width of board(mm) | 180 | 240 | 300 | 600 | 900 |
| Extruder Model | SJZ55/110 | SJZ65/132 | SJZ80/156 | SJZ92/188 | |
| Mian motor power(KW) | 22 | 37 | 55 | 110 | |
| Drawing height(mm) | 150 | 150 | 150 | 150 | 150 |
| Drawing speed(KN) | 20 | 20 | 20 | 30 | 40 |
| Drawing speed(m/s) | 0-5 | 0-5 | 0-5 | 0-3 | 0-2.5 |
| Auxiliary equipment sum power(kw) | 35 | 35 | 30 | 30 | 40 |
| Cooling water consume(m 3 /h) | 6 | 6 | 6 | 9 | 12 |
| Compression air(Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Equipment warranty:
