Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine

Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine
Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine

Large Image :  Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigationwood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month

Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine

Description
Model Number: SJ65/33 Plastic Processed: PE
Voltage: 380V 50HZ Automatic Grade: Fully Automatic
After-sales Service: Engineers Availiable To Service Warranty: 1 Year
Condition: New Port Of Shipment: Qingdao
High Light:

plastic pipe extrusion machine

,

plastic pipe production line

Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Dpuble Wall Corrugated Pipe Making Extruder Machine





Quick detail:



1. Absorbing latest technologies our company can make the diameter of large-apture winding pipe to 200-3000mm, which is becoming the mainstream city drainagepipes gradually replacing steel and cement pipes.



2. Compared with metal, ceramic, concrete and other pipes, double wall corrugated pipe has many advantage such as lower weight, lower cost, easy to connect, due to the special structure of double wall corrugated pipe. So it is used widely for sewerage and drainage system, cable protection system, etc.





Description:



1.Suitable to U-PVC,C-PVC,M-PVC ,PE, PPR,PP,HDPE,LDPE pipe extrusion.PE/PP/PVC double wall corrugated pipe production line with various diameter and wall thickness, from 16-800mm.The plastic pipe production line mainly includes twin screw extruder, pipe extrusion die, vacuum calibrating water tank, spray cooling water tank, hauling unit, cutting unit and stack unit.the extruder is specially designed for producing variours pipe.



2.Adoped the Simens, ABB, Schneider famous brand electric components and high quality extruder alloy screw and barrel.Supply technical service, formula guide and staple raw material purchase.





.Production Line Strucure



Pipe range
20-63mm

20-63mm

75-160mm

110-315mm

315-630mm

Extruder

SJZ51/105

SJZ65/132

SJZ80/156

SJZ80/156

SJZ92/188

Extruder power

18.5kw

37kw

37kw

55kw

110kw

Extrusion capacity

120kg/h

200kg/h

350kg/h

500kg/h

800kg/h

Max. Production speed

12m/min

10m/min

6 m/min

3 m/min

1.2m/min





Technical and after-sales service:


The supplier the following technical and after-sales service commitment
A) Provide on-site installation guide;
B) Responsible for the commissioning of equipment;
C) Responsible for the buyer's personnel mount guard before the operation and maintenance training;
D) One year free warranty (due to the buyer's improper operation caused by damage charge costs), and ensure the supply of spare parts for a long time, only receive the cost.
E) Provide technical advisory services for a long time.

Double Wall PE Corrugated Pipe Extrusion Machinery , HDPE PP Double Wall Corrugated Pipe Making Extruder Machine 0
