Product Details:
|
| Condition: | New | Place Of Original: | Shandong , China |
|---|---|---|---|
| Voltage: | 380V 50HZ | Raw Material: | PP PE |
| Type: | Granulating Production Line | Machine Name: | PP PE Plastic Granulating Making Machine |
| After-sales Service: | Engineers Availiable To Service | Screw Design: | Single Design |
| High Light: | Plastic Pelletizing Machine,Plastic Granulating Machine |
||
Plastic PE Granules Extrusion Machinery , Plastic PE Film Recycling Granules Production Line
QUICK DETAIL:
1. This machine adopts Gentian type double-stage series high foam technology. The raw material is general polystyrene granule, in the extruding process, vesicant is injected at high pressure. After extruding , foaming,, cooling, shaping and hauling off, it is winding to finished ps foam sheet rolls.
2. Fully automatic vacuum forming and cutting off integration machine is all-powerful thermoforming machine with integrating vacuum forming and cutting off at the same time. It can be used for processing all kinds of plastic sheet. This machine adopts computer digital forming system, PLC mechanical and electronic integration self-control and touch screen control working programme, it is easy to operate and has highly production efficiency.
Description:
1. This series extruder is developed by our company adopting german latest advanced technology ,screw optimizes composing separate type screw and mixing parts,barrel optimizes composing groove barrel and lengthened feeing segment,there is advange as following by using separate type screw and groove barrel together.
2. It's optimized extruding melt material in low temperature ,cutting unit is caused through separate clearance and it makes material equal well,it was controlled during plasticization process. Therefore only granulate that smaller than separate clearance can enter melt channel,it also can suitable for material HDPE,PP and ABS pipe.
3. Plastic granulating machine:
The sj extrusion pelletizer line is used to cut and extrude wasted thenoplastics, such as PC PA ANS PP PS PE PVC PPR POM PBT PET TPU etc. And produce granules of the materials. Different screws canproduce different plastics.
Specifications:
| Model | SJW45/33 | SJW60/33 | SJW75/33 | SJW90/33 | SJW120/33 | SJW150/33 |
| Screw diameter(mm) | 45 | 60 | 75 | 90 | 120 | 150 |
| L/D | 33:1 | 33:1 | 33:1 | 33:1 | 33:1 | 33:1 |
| Transmission power(kw) | 37 | 75 | 110 | 160 | 280 | 400 |
| Center height | 1000 | 1000 | 1100 | 1100 | 1100/1300 | 1300 |
| Output(kg/h) | 150 | 300 | 450 | 600 | 900 | 1200 |
