PVC WPC Crust Foam Board Making Machine , WPC Plastic Furniture Foam Board Production Line , Plastic Board Machine
Quick detail:
1. Our PVC foam board machine include the special Twin-screw extruder, mould and other auxiliary machines . We supply you the best material formulation and all of technology. It is with big output, stable extrusion, high foaming, good and wear-resisting surface and so on.
2. Applications:
2.1.usage:transportation:such as steamship, airplane, carriage, traine compartment, roof shed, case core layer, inner upholster, etc.
2.2.Architecture:such as building wall board, decoration board, housing, office, public building interlayer, commercial decoration shelf, non-dust room board, ceiling plate, etc.
2.3.Advertisement:such as screen printing, computer lettering, ad board, etc.
2.4.Industry:such as chemical industry antisepticizing project, thermoforming, for refrigeratroy, for temperature keeping, for environment protection, etc.
Description:
1. WPC PVC foam board machine is applied to produce PVC foam board with width 1220mm to 1830mm, thickness 3mm to 30mm, and with very rigid surface, surface hardness can reach 55-80HRC, which are mostly used for advertising, cabinet, furniture board, consution template and so on.
2. WPC foam board making machine
WPC foam board making/production/extrusion machine are applied in PVC powde+Wooden powder+other additives raw material to produce kinds of wpc foaming board. Adopting our company's special design and unique processing, these lines can produce different proportion (0.55-0.95) profile wood plastic products to meet customer's needs.
3. With different products, we can match different performance twin extruder or single extruder which equipped with auxiliary devices such as vacuum forming machine, haul-off and cutting machine, loading shelves to optimize its capacity. By using moulds which are specially designed with customer's products, customer can produce the products that they need.
Specifications:
|
Model
|
SJSZ-51
|
SJSZ-55
|
SJSZ-65
|
SJSZ-80
|
SJSZ-92
|
|
Screw dia.(mm)
|
51/105
|
55/110
|
65/132
|
80/156
|
92/188
|
|
Max speed(rmp)
|
40
|
38
|
38
|
37
|
36
|
|
Main motor(kw)
|
18.5
|
22
|
37
|
55
|
90
|
|
Capacity(kg/h)
|
80~100
|
100~150
|
150~250
|
250~380
|
380~700
|
|
Center height(mm)
|
1050
|
1050
|
1050
|
1050
|
1100
|
|
Net weight(kg)
|
3000
|
3500
|
4000
|
5500
|
8000
|
|
L*W*H(m)
|
3.6x1.1x2.1
|
3.6x1.1x2.1
|
4.2x1.5x2.4
|
4.7x1.5x2.4
|
6x1.6x2.5
|
Competitive Advantage:
1. Good pre-sales and after-sales service
2. Short delivery time
3. Overseas installation
