Product Details:
|
| Brand Name: | Aorui | Raw Material: | PVC WPC |
|---|---|---|---|
| Application: | Construction Board | Voltage: | 380V 50HZ |
| Certificate: | CE ISO9001 | Automatic Grade: | Fully Automatic |
| Place Of Roiginal: | Shandong, China | Frequency Control: | ABB |
| High Light: | wpc pvc foam board machine,wpc board production line |
||
PVC WPC Foam Board Machine / WPC Building Formwork Extrusion Process / WPC Crust Foam Board Making Machine
Quick detail:
1. WPC PVC foam board production line is applied to produce PVC foam board with width 1220mm to 1830mm, thickness 3mm to 30mm, and with very rigid surface, surface hardness can reach 55-80HRC, which are mostly used for advertising, cabinet, furniture board, constrution template and so on.
2. It use for many fields. Such as: transport industry,architecture decoration industry,advertisement industry,other application. usually using for Kitchen door.Transport industry: ship, plane, bus, train, floor covering, core layer, indoors decoration plate.
3. wpc pvc foam board for construction and furniture extrusion line,
wpc pvc skinning foam board machine line,
wpc pvc celuka skinning foam board extrusion machine,
wpc pvc 3-layers co-extrusion foam sheet production line
Description:
1. PVC foramed plate is a late-model plate of surface crusting with its core layer under foaming treatment which ensures the smooth surface, light weight and strong indensity, and it can be processed like wood plate. PVC foamed plates are widely used in fields of advertise lettering, construction, decoration, windows and doors of furniture, etc.
2. Compared to traditional construction template, it has following advantages:
1.Good water resistance. Even when put in the water for many days, It can still stay in form and won't decay.
2. It won't stick with cement, and is easy to be released from the cement after construction. And it won't deform due to the affection of the cement.
3.High efficience, good quality. The constructure, which uses WPC construction template, has a smooth and even surface. Further decoration is not needed.
4.Saves the working process. By processing the construction template, you can easily stamp the patterns on the wall.
5. Light weight, and convenient
Specifications:
|
Model
|
SJSZ-51
|
SJSZ-55
|
SJSZ-65
|
SJSZ-80
|
SJSZ-92
|
|
Screw dia.(mm)
|
51/105
|
55/110
|
65/132
|
80/156
|
92/188
|
|
Max speed(rmp)
|
40
|
38
|
38
|
37
|
36
|
|
Main motor(kw)
|
18.5
|
22
|
37
|
55
|
90
|
|
Capacity(kg/h)
|
80~100
|
100~150
|
150~250
|
250~380
|
380~700
|
|
Center height(mm)
|
1050
|
1050
|
1050
|
1050
|
1100
|
|
Net weight(kg)
|
3000
|
3500
|
4000
|
5500
|
8000
|
|
L*W*H(m)
|
3.6x1.1x2.1
|
3.6x1.1x2.1
|
4.2x1.5x2.4
|
4.7x1.5x2.4
|
6x1.6x2.5
|
Competitive Advantage:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
