Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line

Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line
Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line

Large Image :  Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month

Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line

Description
Brand Name: Aorui Screw Design: Single Screw
After-sales Service: Engineers Availiable To Service Voltage: 380V 50HZ
Application: Plastic Corrugated Pipe Condition: New
Original: Shandong, China Type: Pipe Making Machine
High Light:

plastic extruder machine

,

plastic production line

Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line



product description



The plastic pipe extrusion production line is mainly used for the production of PE pressure pipes, discharge pipes in the chemical and food fields, protection and conduits for power cables and communication lines, and guardrail pipes for fish ponds. It can process a variety of LDPE HDPE, especially the pellets are processed directly into a tube shape. The screw and barrel it uses are introduced by German technology manufacturing companies (high-efficiency screw barrels with special grooves) with a maximum extrusion capacity of 50KG per hour. Is a very high performance plastic extrusion line



Plastic Pipe Extrusion Line / PE PP PA Single Wall Double Wall Corrugated Pipe Production Line 0



Specifications

Type Pipe Diameter
(mm)
PVC Output
(kg/h)
PE/PP Output
(kg/h)
MAX Speed
(m/min)
Total Power
(KW)
WR-160 90-160 150-250 200-300 6.0 9.7
WR-250 110-250 250-350 250-350 5.0 8.6
WR-500 200-400 650-750 250-500 3.0 16.9
WR-800 500-800 --- 1000-1100 3.0 16.9
WR-1200 800-1200 --- 1000-1200 1.0 30.



Machine advantage



1. AC motor, ABB governor, Japan RKC temperature controller, Schneider contactor.
2. Screw nitriding treatment, hardness HV740-940, surface roughness Ra≤0.8um.
3. Barrel-type air-cooled cooling method, the nitriding depth is 0.5-0.7mm, the hardness is above HV860, and the surface roughness Ra≤1.6um.
4. Die material, high quality steel for quenching and tempering. Structure, hard chrome plated at the point of contact with the material. Bolt level, 12.9 high strength bolts.



Application



PVC threading pipe extrusion production line is mainly used to produce various PVC pipes, which are widely used in agricultural land, water supply and drainage of buildings, and cable laying. The production line consists of a conical twin-screw extruder, a vacuum sizing device, a tractor, a cutting machine and a flip frame.
