Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine

China Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine supplier
Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine supplier Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine supplier Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine supplier Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine supplier

Large Image :  Plastic Double Pipe Making Machine / PVC Twin Screw Pipe Extrusion Machine

Product Details:

Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA
Model Number: SJSZ 51/105

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigationwood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Raw Material: PVC Condition: New
Screw Number: Two Automatic Grade: Fully Automatic
Model Number: SJSZ51/105 Product Type: PVC Plastic Pipe
Motor: Siemens Certificate: CE ISO9001

Plastic PVC Double Pipe Making Machine / PVC Twin Screw Pipe Extruder Machine / PVC Double Pipe Machinery​





Quick detail:



1. PVC pipe extrusion line is mainly used in the manufacture of plastic PVC pipes with various diameters and wall thickness used in the industries such as agricultural and constructional plumbing, cable laying etc. This line is composed of conical twin-screw extruder, vacuum calibration tank, haul-off, cutter and stake etc. The extruder and haul-off adopt imported AC frequency control device, vacuum pump and haul-off motors adopt high-quality products.



2. The haul-off methods are two-claw, three-claw, four-claw, six-claw, eight-claw, ten-claw, twelve-claw etc. You may choose saw blade cutting type or planetary cutting type. It is additionally attached with length counter and intensifying device. This line is of reliable performance and high production efficiency. Our company can also manufacture special pipe production lines, e. G. Spiral silencing pipe and core foaming pipe according to your requirements.







Description:



1. Application:

Diameter 16mm-800mm series PVC pipe extrusion production line is mainly used in the manufacture of plastic PVC pipes with various diameters and wall thickness used in the industried such as agriculture and constructional plumbing, cable laying etc, it also named PVC Pipe Production Line, PVC Pipe making machine.

2. This PVC Pipe Extrusion Line is composed conical twin-screw extruder, vacuum calibration tank, haul off, cutter and stake etc. The extruder and haul off adopt imported AC frequency control device, vacuum pump and haul off motors adopt high-quality products. The haul off methods are two-claw, three -claw, four-claw, and six-claw etc. You may choose saw blade cutting type or planetary cutting type. It is additionlly attached with length counter and intensifying device. This line is of reliable performance and high production effeciency







Production Line Strucure



Extruder Model SJSZ51/105 SJSZ51/105 SJSZ65/132 SJSZ65/132 SJSZ80/156 SJSZ92/188
PVC Pipe.Diameter (mm) 16-40 PVC Dual Pipe 16-63 16-63 PVC Dual pipe 75-160 200-315 630
Motor power (kw) 18.5 18.5 37 37 55 90
Drawing machine (m/min) 0.5-10 0.5-10 0.5-8 0.5-8 0.5-6 0.5-4
Total Length 20 20 25 25 28 32
Output (kg/h) 80-120 80-120 180-250 180-250 280-350 500-600









Our company competitive advantages:



Technical and after-sales service:
The supplier the following technical and after-sales service commitment
A) Provide on-site installation guide;
B) Responsible for the commissioning of equipment;
C) Responsible for the buyer's personnel mount guard before the operation and maintenance training;
D) One year free warranty (due to the buyer's improper operation caused by damage charge costs), and ensure the supply of spare parts for a long time, only receive the cost.
E) Provide technical advisory services for a long time
