Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm

China Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm supplier
Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm supplier Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm supplier Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm supplier Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm supplier

Large Image :  Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm

Product Details:

Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJSZ80/156

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C Western Union
Supply Ability: 10 Sets per month
Contact Now
Detailed Product Description
Model Number: SJSZ80/156 Condition: New
Certification: CE ISO9001 Nitrided Layer Thickness: 0.4-0.7mm
Screw Number: Two Brand Name: Aorui
Temperature Controller: Omron Motor: Siemens

WPC Foam Board Machine , WPC Foam Board Furniture Board Making Machine , Foam Board Extruder





Quick detail:



1. PVC WPC Wood Plastic foam board making machine is continuously improved on the basis of requirements and feedbacks from our customers and combined with foreign advanced technology.



2. Our production lines have two extruders co-extrusion type and three extruders co-extrusion type.Our extruders adopt specially designed screw. We did a lots of study from process to formula. The performance of our machinery and equipment reached the international advanced level.





Description:



1. PVC Crust Foam Board has such characteristics as sound separation, sound absorption, heat separation, temperature-keeping,etc. The material is incombustible, it is safe for use.



2. All series of products have property of moisture proof, mildew proof, water resistance, its vibration resistant effect if good. All series of products have property of weathering proof, its luster may remain forever, it is not easy to be ageing.



3.  This product is light, storage & transport, construction are rather convenient. This product can be worked with normal tools for wooden material. Drilling, sawing, nail, planing, bonding can be conducted like wooden material. It is suitable for thermal shaping, thermal bending and fold processing. It can be welded, it can also be bonded with other PVC material. The surface of this product is smooth, it can be printed.(Clean the surface before printing.)







Specifications:



Model
SJSZ-51
SJSZ-55
SJSZ-65
SJSZ-80
SJSZ-92
Screw dia.(mm)
51/105
55/110
65/132
80/156
92/188
Max speed(rmp)
40
38
38
37
36
Main motor(kw)
18.5
22
37
55
90
Capacity(kg/h)
80~100
100~150
150~250
250~380
380~700
Center height(mm)
1050
1050
1050
1050
1100
Net weight(kg)
3000
3500
4000
5500
8000
L*W*H(m)
3.6x1.1x2.1
3.6x1.1x2.1
4.2x1.5x2.4
4.7x1.5x2.4
6x1.6x2.5









Competitive Advantage:



1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life

3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.

Two Screw Wpc Foam Board Production Line , Nitrided Layer Thickness 0.4 - 0.7mm
