Product Details:
|
| Brand Name: | Aorui | Voltage: | 380V 50HZ |
|---|---|---|---|
| Automatic Grade: | Fully Automatic | Place Of Original: | Shandong, China |
| After-sales Service: | Engineers Availiable To Service | Warranty: | 1 Year |
| Certificate: | CE ISO9001 | Screw Design: | Twin Screw |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Extruder |
||
Plastic PVC WPC Profile Extrusion Line , PVC PP PE Plastic and Wood Foamed Profile and Plate Extrusion Line
Quick detail:
1. it adopts special design of screw and barrel, mould and extruder for wood plastic products. the products series: one step way thick board extrusion line, one step way wpc profile extrusion line, wpc pelletizing extrusion line and different kinds of wpc moulds.
2. The wpc products can be produced by two step extrusion machine, first step to produce the wood pellet by twin screw parallel extruder machine, the second step produce the wpc pp/pe profile by conical double screw extruder.
Specification of pvc wpc Profile Machine:
PVC Decking Profile Extrusion Machinery With Price features:
1) Mainly used to produce the PVC window profiles, plastic decorative plates and PVC
foam profiles
2) Use frequency conversion for speed regulation
3) Has super-taper twin-screw extruder with temperature controlling instrument in the screw core
4) Saves power by 30% - 40%
5) The rigid gear surface of the reducer can be operated continuously for a long
time without trouble
6) Operation and mold changing are smooth and steady
7) Long usage life
8) Can produce steel plastic profiles by changing the wood imitation foaming profile
mold, combines with one set of steel liner conveying devices
Technical Parameters:
| Items | YF180 | YF240 | YF300 | YF600 | YF900 |
| Max.width of board(mm) | 180 | 240 | 300 | 600 | 900 |
| Extruder Model | SJZ55/110 | SJZ65/132 | SJZ80/156 | SJZ92/188 | |
| Mian motor power(KW) | 22 | 37 | 55 | 110 | |
| Drawing height(mm) | 150 | 150 | 150 | 150 | 150 |
| Drawing speed(KN) | 20 | 20 | 20 | 30 | 40 |
| Drawing speed(m/s) | 0-5 | 0-5 | 0-5 | 0-3 | 0-2.5 |
| Auxiliary equipment sum power(kw) | 35 | 35 | 30 | 30 | 40 |
| Cooling water consume(m 3 /h) | 6 | 6 | 6 | 9 | 12 |
| Compression air(Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Our company advantages:
1. CE ISO9001 Certificate
2. We have more than 15 years experience
3. We are factory, and welcome to customer to visit our factory
4. Good pre-sales and after-sales service
5. The customer can send the engineer to our company with training
6. Our engineer can be to the Buyer's company for installation and testing the lines.
7. The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
