Product Details:
|
| Brand Name: | Aorui | Raw Material: | PP PE Waste Plastic |
|---|---|---|---|
| Automatic Grade: | Fully Automatic | Application: | Granules |
| Voltage: | 380V 50HZ | Original: | Shandong , China |
| Certificate: | CE ISO9001 | Screw Material: | Stainless Steel |
| High Light: | Plastic Pelletizing Machine,Plastic Granulating Machine |
||
PE Plastic Granules Machinery / PP PE Waste Plastic Granules Pellet For Recycling Granulator Price
QUICK DETAIL:
1. Product Description:
This water-cooling single screw plastic pellet making machine is one stage plastic regenerative pelletizer, which is suitable for many kinds plastic waste materials recycling and making pellet, such as PP, HDPE, LDPE, LLDPE Film and clean woven/nonwoven bag materials, etc. The film can be pressed in compressor and then be pelletized. Process flow: Conveying feeding→Metal detector→Film agglomerating→Degassing single screw extruder→Hydraulic stainer exchanger→Rub sufface granulating machine→Slip trough→Dewatering machine→Librating screener→Blowing system→Storage hoper→Finished product packing.
Description:
Features:
1. Allow free assembling of the screw component, based on raw material type.
2. Using the suitable die head for palletizing, such as water ring cutting, under-water cutting and hot face cutting.
3. High efficient force feeder ensures stable high capacity material feeding, low power consumption.
4. Main screw has vacuum exhaustion.
5. Water ring granulator machine, attached with dryer. 6. Single screw extruder, with specially designed screw, barrel, venting system, ensure the good quality of the final products.
7. Pelletizing style: standard cutting with extrusion mould. Even cutting ensures with good shape.
Specifications:
| Model | SJW45/33 | SJW60/33 | SJW75/33 | SJW90/33 | SJW120/33 | SJW150/33 |
| Screw diameter(mm) | 45 | 60 | 75 | 90 | 120 | 150 |
| L/D | 33:1 | 33:1 | 33:1 | 33:1 | 33:1 | 33:1 |
| Transmission power(kw) | 37 | 75 | 110 | 160 | 280 | 400 |
| Center height | 1000 | 1000 | 1100 | 1100 | 1100/1300 | 1300 |
| Output(kg/h) | 150 | 300 | 450 | 600 | 900 | 1200 |
Our company competitive advantages:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
