Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet

Good quality Plastic Pipe Extrusion Line for sales
Good quality Plastic Pipe Extrusion Line for sales
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

I'm Online Chat Now

Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet

China Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet supplier
Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet supplier Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet supplier Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet supplier Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet supplier

Large Image :  Plastic Sheet Production Line PP PE Plastic Extruder Machine For Making Hollow Sheet

Product Details:

Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA
Model Number: SJ90/33

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Contact Now
Detailed Product Description
Brand Name: Aorui Application: Sheet
Plastic Processed: PP PE PC Screw Design: Single Screw
Automatic Grade: Fully Automatic Place Of Original: Shandong,China
Model Number: SJ90/33 Voltage: 380V 50HZ

High Quality PP Hollow Sheet Extrusion Line / PP PE Plastic Extruder Machine For Making Hollow Sheet





QUICK DETAIL :



1. Production Line Process flow

Plastic raw material and additive → mixing → spring feeding → double screw extruder → mould and calibrator → vacuum forming machine → haul off machine → cutting machine → stacker



2. Main Features

1) Horizontal structure forming machine.
2) The horizontal, vertical and horizontal direction of the worktable can be adjusted in three dimensions.
3) Automatic power-off protection system for working table.
4) Automatic lubrication center.
5)The module is made of special aluminum alloy, which has the advantages of light weight, high strength, good wear resistance and low coefficient of thermal expansion.
6)The forming module has the advantages of air cooling and water cooling







Description:



1. The pp hollow cross section plate is light and high strength ,moistureproof good environmental protection and refabrication perfor mance.



2. Application;the reusable container,packing case, clapboard ,backing plate ,and culet.packing,printing,Sheet, packing box,advertise board,gasket,constrution,adornment industries.



3. Extruder of PP PE hollow sheet extrusion machine: The specially designed screw and the advanced controlling system ensure excellent plasticization, high output and stable extruding.



Screen changer: Quick screen changer of hydraulic system ensures the short course of screen changing. Double-position combined with special sealing structure guarantee stable operation of screen changer



Mould of PP PE hollow sheet extrusion line: Mould adopts high-quality alloy steel and throttling device and also differential action of up-down piece guarantee even thickness of the plate.







Specifications:





Extruder Model LMSB-90/33 LMSB-100/33 LMSB-120/33 LMS-100/65 LMSB-120/65
Sheet Width 300-610mm 500-950mm 1000-1500mm 500-950mm 1000-1500mm
Sheet Thickness 0.15-1.4mm 0.15-1.4mm 0.15-2mm 0.25-1.4mm 0.25-1.4mm
Driving Motor 75KW 90KW 132KW 90KW,75KW 132KW, 65KW
Line Speed 25m/min 25m/min 28m/min 28m/min 28m/min
Capacity 180kg/h 300kg/h 550kg/h 450kg/h 650kg/h







Competitive Advantage:



experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology

Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.

After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
