Product Details:
|
| Model Number: | SJSZ65X132 | Motor Brand: | Siemens |
|---|---|---|---|
| Temperature Controller: | Omron | Raw Material: | Omron |
| Place Of Original: | Qingdao City | Warranty: | 1 Year |
| Automatic Grade: | Fully Automatic | Voltage: | 380V 50HZ |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Production Line |
||
Conical Twin Screw Extruder Plastic Profile Extrusion Line PVC Profile Profile Machinery
Production line configuration reference( pvc door and window profile extrusion line )
| Item | component | quantity |
| 1. | double screw extruder | 1set |
| 2. | mould | whole 1set |
| 3. | vacuum calibration tank | 1set |
| 4. | hauling machine | 1set |
| 5. | cutter | 1set |
| 6. | stacker | 1set |
Description:
1.PE WPC floor profile is special for outdoor. This machine uses the special designed screw and barrel, die
and extrusion process to produce plastic and wood products.
2.The series of products are: One step thick plastic and wood plate extrusion machine, one step plastic and
wood profile extrusion machine, one step plastic and wood decoration plate extrusion machine, plastic and
wood pelletizing machine and different kinds of plastic and wood dies.
3.This machine can use the one step extrusion method and also it can use the two-step extrusion method
after pelletizing. The two-step extrusion method can save the power and space, and the two-step extrusion
method features the machine can gain the high output and stable extrusion pressure.
4.A pre-heating feeder is mounted on the top of the extruder which extracts the humidity from the wood
powder, so that the feeding section of the extruder can be filled with enough material and the plastification
effect will be better.
5.Special and well designed screw enables the raw material to be evenly stay in the extruder. The screws
and barrel are bi-metallic treated, more wearable and anti-corrosion.
6.The machine can produce PE, PP or PVC and wood profile products. These products are mainly applied
for making pallets, packing cases, floors, wall decoration materials and other wide applications. The wood
powder or plant fiber can be put up to max. 50-75%. This machine can produce the PP, PE, PVC, ABS, PS
and etc
Specifications:
| Model | YF180 | YF240 | YF300 | YF400 | YF500 | YF600 |
| Max. width of product(mm) | 180 | 240 | 300 | 400 | 500 | 600 |
| Extruder model | SJSZ55/110 | SJSZ65/132 | SJSZ65/132 | SJSZ65/132 | SJSZ80/156 | SJZ80/156 |
| Max. extrusion capacity(kg/h) | 150 | 250 | 250 | 250 | 360 | 360 |
| Extruder power(kw) | 22 | 30/37 | 30/37 | 30/37 | 55 | 55 |
| Cooling water(M3/h) | 5 | 7 | 7 | 8 | 10 | 12 |
| Compressed air(M3/min) | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 | 0.5 |
Application:
This PVC pipe Extrusion line is designed with advanced west Europe technology. The extruder is conical twin screw with double screw, it is mainly used for PVC powder. Main used for production pvc wpc profile product.
Competitive Advantage:
1.good after-service
2.spare parts are free
3.guarantee:one year or according to customer’s requirement.
4.advanced technology and best quality
5.international certification standard.
6.our engineer help and teach customer to test the machine.
