Product Details:
|
| High Light: | Plastic Granulating Machine,Plastic Recycling Machine |
||
|---|---|---|---|
Single Wall Corrugated Plastic Pipe Extruder With PLC Control System
Quick detail:
Power supply : 380V50HZ
Ceterfication: CE UL SCA
Motor: Siemens
Port :QingDao
Condition : New
Max. production speed:12m/min
Description:
1) PVC Single Wall Corrugated Pipe production line shall be used to produce small diameter single wall corrugation pipe in PVC,PP and PE raw material.
2). Plastic single-wall corrugated pipes produced by this single wall corrugated pipe machine have many
features such as high intensity, good flexibility,high temperature resistance, resistant to corrosion and
abrasion, etc. They has large market which are widely used in the fields of auto wire, electric thread-
passing pipes, protective pipes of lamps and lanterns wire, circuit of machine tool, tubes of air conditioner
and washing machine and so on.
3) Molding corrugation pipe with smooth inside and outside surface and even ripple at one time by
corresponding die; Used as wire and cable passing pipe ,washing machine drain pipe,dust collector pipe
and ventiduct; Small size corrugation pipe of 4-6.7 are used in car.
4)PE/PP/PVC Single Wall corrugated pipe production line consists of Extruder, Mold Blocks,
Corrugated Forming Machine, Cooling Equipment,Counting Machine and Auto winding system. It can
continuously produce many kinds of diameter single wall corrugated pipe in high speed.
5). Power: 11-125KW
Screw design:single screw
Machine type: pipe production line
Weight: 8T
Capacity: 300kg/h
Diameter of pipe:20-110mm,75-200mm,110-315mm,315-630mm
Control system: PLC
Specifications:
|
Diameter Scope |
4.5-9 |
9-32 |
32-50 |
|
Main Extruder |
SJ-30 |
SJ-45 |
SJ-65 |
|
L/D |
30:1 |
30:1 |
30:1 |
|
Output kg/h |
10 |
40 |
80 |
|
Main Motor Power kw |
4 |
11 |
18.5 |
|
Corrugator Power kw |
1.1 |
1.5 |
1.5 |
|
Mould Block Pairs |
42 |
44 |
44 |
|
Cooling Type |
Water and air cooling |
||
|
Linear Speed (m/min) |
6-10 |
8-12 |
8-15 |
|
Counting Type |
Sensing counting |
||
|
Winding Type |
Automatic/Manual |
||
Applications:
They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine
tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine,
etc.
Competitive Advantage:
1.high temperature resistance
2.high intensity
3.corrosion resistance etc
