PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase

PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase
PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase

Large Image :  PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase

Product Details:
Place of Origin: Shandong China
Brand Name: AORUI
Certification: CE UL CSA
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month

PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase

Description
High Light:

Plastic Extrusion Equipment

,

Plastic Extruder Machine



PP / HDPE Plastic Extrusion Machine Single Screw 380v 50hz 3 Phase



Quick detail:



  Type: pipe machine

  Pipe material : PE HDPE

  Voltage: 380v50HZ 3P

  Certification: CE UL CSA

  Screw design : single screw

  Diameter : under 1200mm

  Application : energy supply pipe

  Processing type : extruding machine

  port: Qingdao port





Description:



Al plate unlocking → Al plate forming machine → Pex material→Vacuum Feeding → Single screw extruder

→ Single screw extruder → Co-extrusion mould → Al plate ultrasonic roll welding machine → Single screw

extruder → Single screw extruder → Co-extrusion mould → Dip-in cooling tank → Dip in cooling tank →

Spray code printer → Belt haul off → Double winder → Steaming for 24hours → Finished product

inspecting& packing





1.   By adopting precision forming technique of aluminum tube, ultrasonic welded aluminum tube will have

precise size and nice roundness.



2.   By adopting the process of co-extrusion in steps for inner and external tubes, binding strength between

tubes is increased, heat accumulation between tubes are avoided, hence, ensure a more smooth surface

of both inner and external  tubes.



3.   PLC control system is adopted by this production line, it has friendly human-computer dialogue

interface, easy to operate and with interlock function. ..



This production line is used to manufacture aluminum plastic tubes and aluminum tubes. Laminated tubes

will be formed in one step by ultrasonic welding and Co-extrusion process. Such aluminum and plastic

laminated tubes are widely applied for cold and hot city water pipes and running pipes of acid, alkali, salt,

other kinds of liquids, fuel gas, oxygen and compressed air etc.





Specifications:



Model

Screw diameter(mm)

L/D

Extruder Qty.

Pipe range(mm)

Capacity (kg/h)

Main motor power(kw)

Total power(kw)

Line length(m)

PEX-AL-PEX32

45mm

25:1

2

16-32

80-150

7.5

90

25

50mm

28:1

2

18.5

PEX-AL-PEX63

45mm

25:1

2

32-63

100-180

7.5

160

30

65mm

28:1

2

37





Applications:



 1) Main machine uses PE high efficiency screw, and notch feeder with powerful water cover cooler, which has greatly improved transmitting capability and ensured extruding. DC running electric machine with British speed adjuster

 2) Applied for the basket-shaped composite electric head for processing Polythene, which not only ensures the stability of high efficiency extruding, but also achieves the minimum stress and highest pipe quality brought by low melting temperature

 3) Adopting high efficiency double-cavity vacuum calibrating technology and spray-paint cooler gullet, which improve the finished product passing rate, and meet the requirements of high speed manufacturing. Vacuum calibrating platform and cooler gullet are all made of stainless steel

 4) Adopting multi-track traction, through the central motor to run all the tracks to reach same height, and ensure roundness of pipes

 5) Adopting fully automatic control system with high precision, reliable operation, easy and convenient handling

 6) Suitable pipe diameter: 20 - 630mm....





 Competitive Advantage:



1. good after-service

2. spare parts are free

3. gurantee:one year or according to customer’s requirement.

4. advanced technology and better quality
