Product Details:
|
| Field: | Construction,environmental | Temperature Controlling Systerm: | Advanced Systerm |
|---|---|---|---|
| Voltage: | 380v/50hz | Power: | 37-75KW |
| Application: | Sheet | Automatic Grade: | Full Automatic |
| Cutting Plate: | Right Angle | Type: | Plastic Production Line, Plastic Extrusion Line |
| High Light: | plastic sheet production line,plastic sheet extruder machine |
||
ABS / HIPS Plastic Sheet Extrusion Line Hot Work Steel for Jelly Cups
QUICK DETAIL :
1. material: grains
2. Mould:hot work steel,5CrNiMo.
3. CE.
Description:
PS/ABS/PP/PE sheet extruder is capable of continuously producing single-layer or multi-layer pp,pe,abs,ps sheet with the width less than 3000mm and thickness of 0.2-2mm,the product are widely used in the fields of stationery,one-off water cups,lunch boxes,jelly cups.beverage cups,food container,thermoforming fields,etc.
Appropriate single-screw extruder(exhaust and non exhaust) should be chosen on the basis of different material,specially designed screw and advanced temperature controlling system ensure the good plasticization,high output and stable extruding.
The products are widely used in the fields of refrigerator, air conditioner, auto, advertisement, and construction, environmental protection, etc.
Extruder:
Appropriate single-screw extruder (exhaust or not) should be chosen on the basis of different materials. Specially designed screw and advanced temperature controlling system ensure the good plasticization, high output and stable extruding.
Three-roller calendaring machine:
Adopts vertical three-roller calendering machine, equipped with roller temperature controlling device, the space of three roller can be adjusted manually and automatically, which has the function of emergency cut off ensure safety.
Bracket of cooling roller:
Equipped with corresponding guide roller, the cooling effect is better. In addition, the edge-shearing and parting off device is equipped which can guarantee fixed width of plates and quality of edge.
Landscape orientation cutting machine:
With cylinder clamping, moving cutting, speed frequency regulating to protect the cutting speed synchronize with plate making speed. Cutting with alloy saw blade, equipped with dust absorption device.
Applications:
1. widely used in field of turnover box, partitions, electronics, home appliances,luggage, food ,pharmaceutical, pesticide, advertising and decorating etc.
2. the advantages of insulation and innocuity, environment friendly and recyclable
Specifications:
|
Model |
Unit |
TYJB-75 |
TYJB-90 |
TYJB-110 |
|
Material applied |
PP,PS,PE |
|||
|
Width of sheet |
mm |
≤600 |
≤750 |
≤1100 |
|
Thickness of sheet |
mm |
0.2-1.6 |
0.2-2.0 |
0.2-2.0 |
|
Extrusion capacity |
kg/h |
60-100 |
100-150 |
150-200 |
|
Diameter of screw |
mm |
75 |
90 |
105 |
|
Installed capacity |
kw |
75 |
90 |
120 |
Competitive Advantage:
1. CE&ISO9001
2. high quality reasonable price
3. Manufacturer
