PE / PP Drainage Pipe Single Screw Extruder Automatic for Building

PE / PP Drainage Pipe Single Screw Extruder Automatic for Building  ​


Quick detail:

1. PE pipes are widely used as water supply pipe, water drainage pipe or gas supply pipe


2. due to its excellent characteristics of high strength,high temperature resistance,corrosion resistance,non-toxic and wear-resisting.It  has become substitute of iron pipe.



Description:

  Flow chart of the PE pipe line

 Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder

→ color code extruder → mould and calibrator → vacuum forming machine → cooling tank

→ haul-off machine → cutting machine → discharging rack

 This PE Drainage Pipe Extrusion Line can be used in PE Large Diameter Gas and Water Pipe which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on.
So, this pipe production line is a preferred gas and water pipe for ductwork system between city and its suburb.
Large diameter HDPE pipes start to play very important role in the city water and gas supply systems.

HDPE pipes has higher resistance to pressure than PE pipe.It is the substitute of traditional iron pipe or water-supply pvc pipe

High efficiency single screw extruder: high rotation speed, high capacity and good compounding effect ensures stable extrusion.

First class pipe die was designed with many years experience , it adopts latest designed die head with spiral distributing flow channel, built-in Temp.control device which make extrusion more evenly and regulution more conveniently.

 Perfect twin pipe vacuum sizing system , advanced water loop vacuum calibration, equipped with adjusting device for roundness and multi-section 6m spraying water tank, ensure perfect calibration; the body of tank is made of stainless steel.

 Controlled independently umlitary structure twin pipe hauling mechanism and synchronous cutting device , can select 2 claw,4 claw,6 claw,8 claw haul off unit to satisfy manufacturing requirements for different pipes.base on different reuirements,we can adopt saw cutting,planet saw cutting and chip-free rotary knife cutting etc.

 Optional length set and accurate adaption stacker, all kinds of control system is available, such as PLC automatic control system, make operation easily and smoothly.

 It’s suitable for PE , PP and other polyolefine pipes high-speed extrusion.The extrusion line has many advantages, such as, nest outline , highly automaticcontrol . stable performance.It’s greatly reputed by the customers due to “European performance and domestic.

The advantaged are high output , high adatability for different raw material, highly stable good-quality extrusion and so on .

Characteristics

• Capacity: single screw extruder, suitable to process PE resin with high capacity, max 1000kg/h
• Diameter: from 16 to 800mm
• Adopts reasonable design, absorbing safe producing technology, acquiring CE&ISO certificate


 Specifications:




Applications:

1. high efficiency , high rotating speed, good compounding effect and stable extrusion ensuring big capacity.
2. extruding die: adopting latest designed die head with spiral distributing flow channel, built-in temperature controlling device which make the extrusion more evenly.
3. controlling system: supply manual controlling cabinet and SIEMENS PLC touch screen contr
4. building hot and cold water systems, including central heating systems;
5, building heating system, including floor, wall and radiant heating systems;
6, can be directly used in purified water drinking water supply systems;


Competitive Advantage:


1. High quality
2. Stable character
3. Reasonable price

4. we have more than 15 years eperiences and our engineers can service overseas.

5. we are factory and we can invite customers to visit our factory to see the machine.

6. we have technique assistance
