Product Details:
|
| Place Of Origin: | Shandong , China (Mainland) | Plastic Processed: | PVC |
|---|---|---|---|
| Screw Design: | Double Screw | Application: | Pipe |
| Condition: | New | Inverter: | ABB |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | ||
| High Light: | plastic pipe extruder machine,plastic pipe extrusion machine |
||
PVC Plastic Drainage Pipe Extrusion Machinery , PVC Conical Twin Screw Production Line
Quick detail:
1 . output:60-700kg/h
2 . pipe diameter:16-800mm
3 . ISO&CE standard
4 . test before delivery
Description:
The working process of PVC conduit pipe making machine:
PVC powder + additive → mixing → spring feeding → twin screw extruder → mould and calibrator → vacuum forming machine → haul off machine → cutting machine → discharging rack
1. It is a high-tech enterprise which is specialized in research, manufacture and marketing plastic extrusion lines,plastic production line.
2.Our plastic extrusion lines based on Plastic Extruders:Single Screw Extruder,Conical Twin Screw Extruder and Parallel Twin Screw Extruder.
3.Our plastic making machine can make many kinds of plastic productions like:PVC pipe,CPVC pipe,PE/HDPE/PE-RT pipe,PP-R pipe,plastic foamed profile,WPC profile and panel,wood plastic composite and so on.
4.Plastic Extuder is widely used in Plastic industry.It is the main part of Plastic Pipe Extrusion Line, Plastic Profile Extrusion Line,Plastic Recycling Line and Plastic Granulating Line.
5.We provide plastic machine which can make Agriculture pipe,machines to produce pellet,laminating machine,wooden window frames machine.
6.Our plastic extruder use good quality screw in plastic machinery.Our plastic machine have long-life.
Specifications:
|
Main Technical Parameters |
||||||
|
MODEL |
PVCG-110 |
PVCG-160 |
PVCG-250 |
PVCG-315 |
PVCG-400 |
PVCG-630 |
|
MATCHED EXTRUDER |
SJZ51/105 |
SJZ65/132 |
SJZ65/132 |
SJZ80/156 |
SJZ80/156 |
SJG92/188 |
|
OD RANGE(mm) |
50-110 |
50-160 |
75- 250 |
110-315 |
200-400 |
315-630 |
|
LENGTH OF VACUUM CALIBRATOR TANK(mm) |
6000 |
6000 |
6000 |
6000 |
6000 |
6000 |
|
HAUL SPEED(m/min) |
0.6-6 |
0.5-5 |
0.4-4 |
0.3-3 |
0.2-2.5 |
0.2-1.5 |
|
INSTALLED POWER(kw) |
67 |
85 |
95 |
125 |
135 |
255 |
|
TOTAL LENGTH9(mm) |
17000 |
18000 |
20000 |
20500 |
28000 |
30000 |
Applications:
1 . It is mainly used to produce PVC conduit pipe.
2 . mould: change molds to produce different pipe products.
3 . After-sales Service Provided: Engineers available to service machinery overseas
Competitive Advantage:
1 . High-quality equipment and highly competitive market prices can bring you more profits.
2 . Good after-service , spare parts are free
3 . advanced technology and better quality
