Product Details:
|
| Certification: | CE BV ISO9001 | Condition: | New |
|---|---|---|---|
| Screw Sedign: | Single Screw | Brand Name: | AORUI |
| Application: | Pipe | Automatic Grade: | Fully Automatic |
| Raw Material: | PE PPR PERT | Place Of Origin: | Shandong , China(Mainland) |
| High Light: | plastic pipe extrusion machine,plastic pipe production line |
||
PE Plastic Extrusion Line , PE Cool And Hot Water pipe Production Line
Quick detail
1. pe cool and hot water pipe production line pe pipe production line single screw pipe plastic extrusion machine.
2. High efficiency extruder is designed for HDPE pipe, equipped with reducer which is high speed and low noise, feeding section with cooling unit and reversing spiral groove, different pitch undulant screw which allows great output, lower melting temperature, and lower energy consumption.
Description:
1. PE pipe extrusion line is developed by our company was based on European advanced technology and have many years for the extrusion machine. Advanced design , reasonable structure , high reliability ,high degree automation of the compelte line.
2. Extruder with special feeding structure can largely improve extrusion capacity.
3. Accurate temperature control , good plasticization , stable oreration.
4. The complete line adopts PLC control system , realizing synchronization and automation.
5. Huamn computer interface is easy to operate , convenient and reliable.
6. Spiral and basket style for choice.
7. Dust-free knife cutter and saw cutter for choice.
8.Changing some parts of the line can also realize two-layer and multi-layer co-extrusion
9. Changing some parts of the line can also produce PPR PERT pipes.
Main Technical Parameter
| Extruder | SJ65-30B | SJ-90/30B | SJ-120/30B | SJ-150/30B |
| SJ-30/25B | SJ-45/30B | |||
| SJ-25/25B | SJ-25/25B | SJ-25/25B | SJ-25/25B | |
| Pipe Dia(mm) | 20-63 | 20-160 | 110-400 | 315-630 |
| Water Sizing Trough | SGZL-75 | SGZL-160 | SGZL-400 | SGZL-630 |
| Water Cooling Trough | SGPL-75 | SGPL-160 | SGPL-400 | SGPL-630 |
| Haul off Machine | SLQ-75B | SJQ-160B | SLQ-400B | SLQ-630B |
| Cutting Machine | STG-75 | STG-160 | STG-400 | STG-630 |
| Stacker | FZ-6000 | FZ-6000 | FZ-6000 | FZ-6000 |
Our Advantages:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
