High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line

High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line
High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line

Large Image :  High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE & ISO9001
Model Number: SJSZ51/105
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter

High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line

Description
Certification: CE&ISO9001 Dimension: According To Model
After-sales Service: Engineers Avliable To Serive Material: PVC
Place Of Origin: Shandong , China (Mainland) Screw Design: Double Screw
Voltage: 380v Plastic Processed: PVC
High Light:

plastic pipe extruder machine

,

plastic pipe extrusion machine



High output Twin Automatic Pvc Pipe Cutting Machine 380 Voltage



Quick detail



PVC fiber reinforced hose Machine (20-50mm)

PVC soft Pipe making machine

PVC fiber reinforced pipe machine

PVC hose production line

8-75mm PVC fiber reinforced hose extruding machine/line

PVC fiber reinforced soft pipe extrusion line plastic machinery





Description:



1. Working flow

Main extruder Die Braider Cooling bath Drying tank Haul off Winder Ink printer Electric cabinet



2. This line is the newly-developed product of our company, which is mainly used to produce PVC fiber reinforced soft pipes. This kind of pipe is characterized by innocuity, transparency, pressure resistance, pulling resistance, acid and alkali resistance, good-looking appearance, tenderness and handiness, durability, etc. So the final products of this line are widely used in conveying pipes for water.



3. This line consists of extruders, spraying water tanks, hauling-off units, Coiler, etc. And it features with reasonable configuration, special structure, easy operation, convenient maintenance, high continual production capacity, etc, so it gets warm welcome and trust from clients.



4. Equipment list :

1. Feeding system two sets

2. single screw extruder two sets

3. Electric control system two sets

4. Extrusion mould and coating mould two sets

5. Cooling water tank two sets

6. Belt haul-off machine two sets

7. Fiber braiding machine one set

8. Double-position winder one set

9. Oven one set









Main Technical Parameters:

Extruder Model SJSZ-51X105 SJSZ-65X132
Accessory Machine GFDP-63 GFDP-63
Pipe Diameter 16-63mm 16-63mm
Production Speed 12(m/min) 12(m/min)
Max.Output 160(kg/h) 220(kg/h)





Our advantage:

1. We have more than 15 years experience in this field

2. High quality and reasonable price

3. our engineers availiable to go abroad to serive and train local workers until they can operate the machine

High output Twin Automatic Pvc Pipe / PVC Twin Screw Extruder Pipe Production Line 0
