Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise

Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise
Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise

Large Image :  Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE&ISO9001
Model Number: SJSZ92/188
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter

Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise

Description
Automatic Grade: Fully Automatic Place Of Origin: Shandong , China
Condition: New Voltage: 380v
Certification: CE&ISO9001 Brand Name: AORUI
Material: HDPE Processing Type: Extrusion
High Light:

Plastic Extruding Machine

,

Plastic Extrusion Equipment

Automatic Plastic Pipe Extrusion Line , Sprial Hdpe Pipe Production Line low noise


Quick detail:

  Our large diameter sprial pipe production line comes both from the outstanding technology of Korea and abundant experiences. it features large output , high efficiency , steady operation , high ring stiffness , light weight per meter , good creep resistance performance , easy connection and economical construction.


Description:

1. 1) The investment is lower and the automatic control system is easy for operation and maintenance.
    2) Adopt winding method by winding the semi-round two side circle profile

    3) The inner PE-layer is Composited with the U-type pipe in melting condition. And they will never been   delaminated after spraying cooling forming, with good adhesion effect.
    4)Adopting Electric-magnetic heating system which can save 40% to 60% electric power.
    5)All Electric Part (breaker/motor/INCKO/Inverter) is Siemens/Schneider/Omron
    6)Production Speed is 1-20m/min.
    7)Max. Pipe Size: 3000mm.

2. single-wall corrugated pipe production line developed by our company adopts gears to run moulds and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe wall. These corrugated pipes are especially used as wires of the up-market cars.

3. The HDPE large diameter hollow wall winding pipe production line is designed with advantaged technology. It is featured with high speed and excellent extrusion quality by adopting two sets of high efficiency single screw extruder. Unique design of composite die head for large diameter winding pipe processing with high production efficiency. High quality of winding pipe produced by adopting the unique winding process.


Specifications:

Diameter Scope

4.5-9

9-32

32-50

Main Extruder

SJ-30

SJ-45

SJ-65

L/D

30:1

30:1

30:1

Output kg/h

10

40

80

Main Motor Power kw

4

11

18.5

Corrugator Power kw

1.1

1.5

1.5

Mould Block Pairs

42

44

44

Cooling Type

Water and air cooling

Linear Speed (m/min)

6-10

8-12

8-15

Counting Type

Sensing counting

Winding Type

Automatic/Manual



Applications:


1. It is widely used in such fields as irrigation (draining and feeding water), protecting the surface of cable, ventilation, exhaust, etc.


2. . used in many fields like Chemical industry, chemical fiber, food, forestry, pharmacy, light industry and papermaking, metallurgical and other industrial raw material conveying pipe.

3. Mainly used in the area of agricultural water supply systerm , architectural water supply systerm , pavement of cables , ect.


Competitive Advantage:

1 . High capacity and stable operation , Long service life and good quality , Low energy consumption
2.  Our engineers can go to aborad to service , install the machine nad test the machine.
3.  We have CE&ISO9001 certificate
4. We have more than 15 years experience.
