Product Details:
|
| Brand Name: | AORUI | Screw Design: | Double Screw |
|---|---|---|---|
| Certificate: | CE & ISO9001 | Dimension(L*W*H)): | According To Model |
| Name: | Wpc Profile Extrusion Machine | Screw Material: | 38Cr MOAIA |
| Place Of Origin: | Shandong , China | After-sales Service: | Engineers Availiable To Service |
| High Light: | wood plastic composite extrusion machine,wood plastic machine |
||
WPC Profile Making Manufacturing Plastic Machine , Plastic Celling Profile Extrusion Machine
Quick detail:
1. WPC profile making machine is used to produce the decking board which is apply to be decorative panels, outdoor flooring, guardrail post, tech pavilion, garden fence, balcony guardrail, field fence, leisure bench.
2. Production flow of WPC profile:
Material batching mixing-palletizing (for PVC type WPC, this step can be skipped.)-Extruding-molding-vacuum calibrating and cooling-hauling-cutting- final WPC profiles
Description:
1. WPC profile extrusion line is adopted specially designed screw,barrel,mould and unique WPC craft and formula initiated by our company. The extruder can match with the auxiliary machines and moulds perfectly.
2. A pre-heating feeder is mounted on the top of the extruder which extracts the humdity fron the wood powder , so that the feeding section of the extruder can be filled with enough material and plastification effect will be better. Special and well designed screw enables the raw material to be evenly stay in the extruder.
3. The whole production line is of automatic control from the loading to the final discharging. The machines can also be manually adjusted separately. With the advantages of good plastication, low energy-consumption, high output, excellent performance, long endurance,ect.
4. The relevant components including followings:
1. Mortor and drive section
2. Barrel heating resp cooling
3. Screw temperature control
4. Optimizing the processing unit.
Specifications:
| Model | YF160 | YF180 | YF240 | YF300 | YF400 | YF500 |
| Max. width of profile(mm) | 160 | 180 | 240 | 300 | 400 | 500 |
| Installed power(Kw) | 18 | 26.1 | 31.6 | 31.6 | 31.6 | 37.6 |
| Cooling water (m3/h) | 5 | 5 | 7 | 7 | 8 | 10 |
| Compressing air(Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
