WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder

China WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder supplier
WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder supplier WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder supplier WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder supplier

Large Image :  WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder

Product Details:

Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJSZ80/156

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Contact Now
Detailed Product Description
Name: Board Machine Thickness: 1-40mm
Density: 0.38-0.8mm Width: 3000mm(under)
Delivery Time: About 35days Temperature Controller: Omron
Frequency Control: ABB Automatic Grade: Fully Automatic

WPC Board Making Machine Production Line , PVC WPC Hollow Door Board Extruder


Quick detail:



1. Plastic+Wood Sawdust board making machine/WPC PVC door production line:



wpc board production line mainly use PVC+wood powder to extruder wpc profiles,such as decking,skirting stair handrails etc.Meanwhile,this production line can also produce pure pvc products,such as door&window frame,ceiling etc.



2. Working Process of wpc board production line

PVC powder +wood powder+ additives → Mixer → Screw feeder → Extruder → Mould → Vacuum forming table→ Haul-off machine→ Cutting machine → Stacker



Description:



 Final Production's features &application of wpc board production line

1. It can be used either and outer door board, partition, window sill etc. or PVC and PVC +wood extruding

foaming craft.

2. The final products produced by the PVC door board extrusion line centralizes the characters of plastic and wood

3. It not only has the special apperance effect, but also overcome the shortage of wood. It has good processability

as wood, and the proportion can be controlled in 0.6-0.9kg/m.

4. It can be sawed, drilled, and planed by the wood working tools.



WPC Board Making Machine , PVC WPC Hollow Door Wood Plastic Extruder



The milk fat content is standardised in a direct standardisation system. Standardised milk used for producing whole milk powder is not normally homogenized.
In the production of dried whole milk the heat treatment must be so intense that the lipases will also be inactivated. This normally involves high-temperature pasteursation to a negative peroxidase test.
Falling-film evaporators are generally used for concentration, which is carried out in two or more stages to a DS content of 45 – 55%.





Specifications:



Model   JG-MSC80/156 JG-MSC80/156-FH
Screw dia. mm Ø80/Ø156 Ø80/Ø156 Ø65/Ø132
Screw quantity piece 2 2 2
Screw speed r/min 1-37.7 1-37.7 1-39.1
Main extruder power KW 75 75 37
Heating power KW 36 36 24
Extrusion output kg/h 150-350 250-450 250-450
Model BF600 BF1220
Max. product width mm 600 1220
Draw-off height mm 150 150
Draw-off force KN 50 50
Draw-off speed m/s 0-3 0-2.5
Total power of auxiliary machine KW 35 40
Cooling water consunmption m3/h 9 12



Application:



WPC usage:



(1) WPC is used to make construction panel, decoration panel, balustrade, pavement, steps, outdoor tables, wall panel and chairs, pergola, tree bed, etc.



(2) Material: 30-40% straw, wood flour, rice chaff mixed with recycled PVC, PP, PE powder.



(3) WPC advantage: undecomposable, deformation free, fade resistant, insect damage resistant, good fireproof performance, crack resistant, and maintenance free etc.


Competitive Advantage:

1. Good quality and reasonable price



2. Engineers availiable to service



3. Good pre-sale and after-sale service



4. CE & ISO9001 xertificate
