Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine

China Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine supplier
Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine supplier Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine supplier Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine supplier Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine supplier

Large Image :  Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine

Product Details:

Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE & ISO9001
Model Number: SJ90/33

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Detailed Product Description
Certificate: CE & ISO9001 Brand Name: AORUI
Condition: New Automatic Grade: Fully Automatic
Place Of Original: Shandong , China Inverter: ABB
Plastic Processed: PP PE Model Number: SJ90/33

Single Screw PE Pipe Production Line , PE Cool and Hot Wter Pipe Making Machine





Quick detail



1. This line is mainly used to produce HDPE pipe for water/gas supply, and sewage and drain pipe, also undergroud pipes. Pipe diameter range: 20-800mm. Capacity: 150-1000kg/h.



2. Special single screw extruder for polyolefin , having high extruding velocity and effective plasticzation. Separation mixing screw specialized for polyolefin.



3. Single screw extruder
adopts long L/D, high efficiency screw, high extrusion capacity, uniformed plasticization. Extruder and haul off machine motors adopt imported AC/DC inverter as speed regulators.





Description:



1. The screw of the extruder is equipped with barrier unit and mixing structure,and the barrel owns new style grooves.All of these offer good plastification and mixing effect.Special design of basket die head for HDPE(PP,ABS)large diameter pipe with thick wall offer lower melting temperature,good mixing,lower pressure of caavity,and stable production.



2. Change the production line is the AORUI company developed a new type of pipe production line for PE, pp jing and other polyolefin pi extrusion speed,all models with advanced PLC/PCC modular intelligent control system,in order to realize the whole production line automation and real-time data recording and closed-loop control,the production line has some high yid,wide adaptation of raw materials,sustained and stable production of high quality products such as columns a bit.






Application:





  The production line is mainly used to manufacture for PE plastic pipe, and GF serirs tube auxiliary equipment production line can also be used to produce other plastic, Extruder and GF series tube auxiliary equipments production line take the features of advantages ,reliability and applicability together, and provide strong certification for high-quality plastic tube for customers.







Main Technical Parameters





Model
PE-16/63

PE-20/110

PE-50/160

PE-75/250

PE-110/315

PE-200/450

PE-315/630

PE-400/800

Pipe diameter

16-63mm

20-110mm

50-160mm

75-250mm

110-315mm

200-450mm

315-630mm

400-800mm

Max output

150kg/h

200kg/h

300kg/h

350kg/h

400kg/h

500kg/h

850kg/h

850kg/h

Extrusion speed

1-15m/min

1.2-12m/min

0.6-8m/min

0.5-4m/min

0.4-3.7m/min

0.3-3m/min

0.2-2m/min

0.1-1 m/min

Extruder model

SJ-65/30

SJ-65/33

SJ-75/33

SJ-75/33

SJ-75/33

SJ-90/33

SJ-120/33

SJ-120/33

Installed power

85kw

110kw

125kw

180kw

260kw

325kw

480kw

600kw

Center height

1000mm

1000mm

1000mm

1000mm

1100mm

1100mm

1200mm

1300mm

Line length

35m

38m

38m

40m

42m

52 m

60m

68m





Our comapny competitive:



  • 24 hours services;
  • Overseas installation;
  • Free operation training and technology formula transfer;
  • Old machine update;
  • Spare parts and maintenance with reasonable cost price.
