PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder

China PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder supplier
PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder supplier PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder supplier PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder supplier

Large Image :  PVC Fiber Reinforcing Soft Pipe Making Machine Double Screw Extruder

Product Details:

Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJSZ51/105

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Detailed Product Description
Model Number: SJSZ51/105 Place Of Original: Shandong , China
Automatic Grade: Fully Automatic After-sales Service: Engineers Availiable To Service
Warranty: One Year Voltage: 380V 50HZ
Plastic Process: PVC Brand Name: AORUI

Plastic PVC Pipe Production Line , PVC Fiber Reinforcing Soft Pipe Making Machine / Pipe Extruder





Quick detail



1. Process Flow of soft PVC garden hose production line:

Raw material+additive→mixing→granulating→conveying feeding→single screw extruder→extruding mould→spray cooling water tank→belt haul-off→fiber winder→warm-up oven→single screw extruder→mould→spray cooling water tank→belt haul-off→meter measure→winder→finished product inspecting&packing.



2. Features:

1. High efficiency single screw extruder.

2. It can produce fiber reinforced brainded flexible pvc hose.

3. The diameter is from 6mm to 60mm, length as customers' request.

4. This hose is mostly used for drainage of light chemicals , irrigation in house, garden, field and construction industry.





Specifications:



1.This extrusion line is designed to produce PVC fiber reinforced hose, the wall of which is three layers, the outer layer and the inner layer both are soft PVC hose, the middle layer is Terylene fibernetwork, which has good chemical and physical property. It is mainly used for the transfer of oil, air,water,high pressure or corrosive gas, chemical, agriculture irrigation and building.



2. The production line is used in producting pvc reinforced pipe, which is widely used in the fields of industry,agriculture, forest, architecture etc. Completed with two single screw extruders, one yarn braid machine and other auxiliary.


3.With different dies,it can produce different soft pipes.The PVC Fiber Reinforced Flexible Pipe, also referred to grid pipe or snake skin pipe, is widely used to convey the middle pressure or corrosive gas and liquid.







Applications:



Now it is widely used in such fields as mechanical engineering, coal min, petroleum, chemical industry, agriculture irrigation and civil applications (solar water heater or gas-canisters). At the present time, it is widely used to the irrigation pipe to the garden and lawn.





Main technical parameter



Model Main motor power(kw) Capacity(kgs/hr)
LXSJ-50/28 11 35-50
LXSJ-65/28 18.5 50-80
LXSJ-90/28 37 80-120







Why choose us:



experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology

Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.

After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
