Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line

Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line
Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line

Large Image :  Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA
Model Number: SJ90/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigationwood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month

Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line

Description
Model Number: SJ90/33 Condition: New
Frequency Control: ABB Payment Terms: TT Or L/C
Temperature Controller: Omron Certificate: CE ISO9001
Brand Name: Aorui Application: PE Pipe
High Light:

plastic pipe extruder machine

,

plastic pipe production line

Water / Gas Supplying HDPE Pipe Extrusion Line , PE Pipe Production Line


Quick detail:

1. Process Flow
Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder → color code extruder → mould and calibrator → vacuum forming machine → cooling tank → haul off machine → cutting machine → stacker



2. Characteristics
1, The extrusion line produces PP, PE ,PPR, ,HDPE ,LDPE and water pipe.
2, The unit consists of single screw extruder, vacuum calibration tank, haul-off, cutter and stacker etc.
3, This line is of reliable performance and high production efficiency.
4, Our company can also manufacture PVC pipe extrusion line,UPVC pipe extrusion line etc.





Description:

1. Pipes made from PE are usually manufactured by extrusion.This process starts by feeding plastic material from a hopper into the barrel of the extruder.The material is gradually melted by the mechanical energy generated by turning screws and by heaters arranged along the barrel.The molten polymer is then forced into a die,which shapes the polymer into a pipe that hardens during cooling.



2. The main extruder adopts PE high-efficiency screw, notched feeding cylinder and strong water jacket cooler, which greatly improves its transmission capacity.The high-efficiency double-cavity vacuum calibrating technology and spray cooling tank improve the rate of finished products.This pipe extrusion line adopts multi-pedrail tractor to drive all pedrails through central motor to get synchronous height and guarantee pipe's roundness.And the high-speed, precise designed cutting machine is low in noise.





.Production Line Strucure

type pipe spec(mm) extruder max.output(kg/h) total power
WR-PE63 20-63 SJ65/33+SJ25/25 100-120 104
WR-PE160 63-160 SJ65/33+SJ25/25 120-300 130
WR-PE250 75-250 SJ75/33+SJ25/25 280-400 260
WR-PE450 160-450 SJ90/33+SJ25/25 500-700 400
WR-PE630 315-630 SJ120/33+SJ25/25 700-900 500
WR-PE800 450-800 SJ150/33+SJ25/25 1000-1100 707






Application:

Our PE pipe production line is mainly used in the production of water supply and drainage pipes , which used for water supply, natural gas and gas transmission, landscaping pipe network, sewage treatment and power threading. This line is characterized of reliable performance, high production efficiency and anti-noise.





About Our Company:

experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
