Product Details:
|
| Brand Name: | Aorui | Place Of Original: | Shandong , China |
|---|---|---|---|
| Port: | Qingdao | Type Of Extruder: | Single Screw Extruder |
| Automatic Grade: | Fully Automatic | Voltage: | 380V 50HZ |
| Warranty Time: | 1 Year | Tmperature Control: | Omron |
| High Light: | Plastic Extruding Machine,Plastic Extruder Machine |
||
PE Plastic Pipe Extrusion Machine , Plastic PE Pipe Making Machine For Water Supply
Quick detail:
1. The drip irrigation pipe technology is associated promotion project between us and China Institute of Water Resources and Hydropower Research developed water-saving drip irrigation, got the national invention patent, and awarded the 1st prize in national project application results in 2010 as well.
2. The machinery can produce pipes continuously with high speed, have the thickness of the wall distributed steadily, with high dripper inserting frequency, and easy to operate. Irrigation pipe can be used in cotton, fruit, vegetables, greenhouse, plant engineering, and other water-saving irrigation area.
Description:
1. This line is a new type of pipe production line for PE , pp and other polyolefin pipe extrusion speed , all models with advanced PLC modular intelligent control system , in order to realize the whole production line automation and real-time data recording and closed-loop control , the production line has some high yield , wide adaptation of raw materials , suatained and stable production of high quality productions such as columns a bit .
2. This hose pipe making machines are mainly used for producing garden pipes, water supply pipe and drainage in construction, cable etc. PE possession of medium density polyethylene pipe and high density polyethylene pipe. SDR11 divided according to the thickness and SDR17.6 series. The former applies to transport gaseous artificial gas, natural gas, liquefied petroleum gas, which is mainly used to transport natural gas.
Main Technical Parameters
| Model | Pipe diameter mm | Extruder | Max. output (kg/h) | Total installed power (KW) | Lenght of production line(m) |
| PE-32 | Φ4-32 | SJ-45/30 | 30-120 | 45 | 28 |
| PE-63 | Φ20-63 | SJ-60/33 | 120-220 | 100 | 36 |
| PE-110 | Φ20-110 | SJ-65/33 | 150-250 | 120 | 39 |
| PE-160 | Φ63-160 | SJ-65/33 | 120-270 | 150 | 43 |
| PE-250 | Φ75-250 | SJ-75/33 | 280-400 | 230 | 45 |
| PE-450 | Φ110-450 | SJ-90/33 | 450-600 | 350 | 65 |
| PE-630 | Φ315-630 | SJ-120/33 | 700-950 | 550 | 75 |
| PE-800 | Φ400-800 | SJ-150/33 | 800-1200 | 700 | 75 |
About Our Company:
Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
