Product Details:
|
| Place Of Original: | Shandong , China | Port: | Qingdao |
|---|---|---|---|
| Payment Terms: | TT Or L/C | Brand Name: | Aorui |
| Motor: | Siemens | Raw Material: | PE |
| Certificate: | CE ISO9001 | Automatic Grade: | Fully Automatic |
| High Light: | plastic extrusion machine,plastic production line |
||
Sprial Corrugated Pipe Making Machine , HDPE Sprial Carbon Corrugated Pipe Extrusion Machines
Quick detail:
1. China HDPE Spiral Corrugated Pipe Plant / Making Machinery
This kind of corrugated pipes has special thread shape modelling,good anti pressure, impact resistant performance , greatly exceeding the technology standards GB/T13381.9 . As the qualitative light, intensity, high temperature resistance, corrosion resistance, length randomly, camber freely, it can make the quick and convenient construction. Its will be no broken ,the service life could be more than 50 years.
2. Pipe diameter can be adjusted.It can produce stainless steel, galvanized steel, aluminum and copper.High-speed flying saw cutting system. PLC control, variable frequency speed regulation. Automatic saw blade cutting system.
Description:
1. It's a kind of new generation high performance plastic spiral pipe line for large diameter buried drain pipe according to pipe production technology by AORUI company with the intellectual property. It can produce pipe size from Ø200~Ø3000mm which is widely used in fields of civil water drain, wastewater drain. The pipe could also be made by the recycled polyethylene material. These properties make it superior advantages compared with other kinds of drainage pipe.
2. The features of hdpe pipe making machine
1) Light weight-per-meter
2) Belling link, tight cementation
3) Pressure against, high strength
4) Anti-frozen and long service life (50 years )
5) Convenient construction
Specifications:
| Model | Pipe range(mm) | Extruder | Total installed power | Max output | |
| Model | Power od main motor | ||||
| RJ-800SP | 200-800 |
RJ-80-34 RJ-65-34 |
110 75 |
280 | 600 |
| RJ-1200SP | 400-1200 |
RJ-100-34 RJ-65-34 |
185 75 |
360 | 750 |
| RJ-1800SP | 800-1800 |
RJ-100-34 RJ-65-34 |
185 75 |
380 | 800 |
| RJ-2400SP | 1400-2400 |
RJ-100-34 RJ-80-34 |
250 110 |
500 | 1000 |
| EJ-3000SP | 2400-3000 |
RJ-120-34 RJ-80-34 |
250 110 |
520 | 1000 |
Applications:
HDPE spiral carbon corrugated pipe is widely applied to beautifying the streets ,street light ground engineering for cities, residential construction, park and golf course,industrial park construction,agricultural drainage and irrigation and water conservancy project,and reform of city network cable buried convenient, telecommunications cable, highways, substation, water conservancy projects, etc.
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
