Product Details:
|
| Condition: | New | Voltage: | 380V 50HZ |
|---|---|---|---|
| Warranty: | 12 Monbths | Type Of Extruder: | Single Screw Extruder |
| Application: | PE Pipe | Automatic Grade: | Fully Automatic |
| Payment Terms: | TT Or L/C | Certificate: | CE ISO9001 |
| High Light: | plastic extruder machine,plastic extrusion machine |
||
Plastic Pipe Extrusion Line , HDPE LDPE Plastic Sprial Pipe Making Machine
Quick detail:
1. Spiral Corrugated Metal Culvert Pipe Making Machine
The Spiral Corrugated Metal Culvert Pipe Making Machineis widely used in highway,railway,culvert channels,bridges,temporary pavement,drainage channels and a variety of mine roadway retaining wall supporting projects.
2. Feature of Spiral Corrugated Metal Culvert Pipe Making Machine
Equipped with plasma cutting machine for smooth cutting
Automatic forming, cutting and unloading process.
PLC control system with cutting length, quantity setting
Description:
1. Our large diameter sprial pipe production line comes both from the outstanding technology of Korea and abundant experiences. It features largeoutput , high efficiency , steady operation , high ring stiffness , light weight per meter, good creep resistance performance , easy connection and economical construction.
2. High technology: We have developed our own technology for this machine. We make all the mould blocks by ourself. High production speed: 20-30m/min, with water cooling, with new technology mould blocks, the line speed can reach to 20-30m/min, it is about three times of others. As our forming machine is equipped with 72 pairs of mould blocks, but the normal one only with 50 pairs.
3. Double size on the same mould block: There are two pipe sizes on the same block, so the manufacturer can change the pipe diameter by adjusting the forming machine up and down. The mould blocks are not connected by chain piece by piece, and the blocks can move forward or backward on the mould base.
Specifications:
| Model |
Pipe Diameter Range (mm) |
Extruder Model
|
Producing speed of line (m/h) |
Max. output (kg/h) |
Total installed power (KVA) |
Overall Dimension L×W×H |
| SDCR-800 | 300-800 |
SDSJ-65×33 (2sets) SDSJ-40×30 (1sets) |
1-30 | 400 | 170 | 17×8×4.0 |
| SDCR-1200 | 300-1200 |
SDSJ-80×33 (2sets) SDSJ-40×30 (1set) |
1-20 | 800 | 270 | 20×10×4.8 |
| SDCR-2000 | 1000-2000 |
SDSJ-90×33 (2sets) SDSJ-50×33 (1set) |
1-18 | 1200 | 350 | 22×12×5 |
| SDCR-3000 | 1800-3000 |
SDSJ-100×33 (2sets) SDSJ-50×33 (1set) |
1-10 | 1500 | 400 | 25×12×7 |
Applications:
high rigidity, light weight, low costs, good sealing performance of the connector; acid and alkali resistance, corrosion-resistance, and long service life, convenient for construction. The pipe is widely used as the underground water drainage system.
FAQ:
Q1:Are you a trading company or a manufactory? A1:We are a manufactory,so we can give u the best service .
Q2:What's your guarantee or the warranty of the quality if we buy your machines? A2:We offer you high quality machines with 1 years guarantee . we will give you spare part free in 1 years
Q3:When can I get my machine after I paid? A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives? A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts? A5:After we deal down all the things , we will offer you a spare parts list for your reference.
