Product Details:
|
| Brand Name: | Aorui | Model Number: | SJ45/33 |
|---|---|---|---|
| Temperature Controller: | Omron | Frequency Controll: | ABB |
| Automatic Grade: | Fully Automatic | Screw&Barrel Material: | 38Cr MOAIA |
| Port: | Qingdao | Type Of Extruder: | One |
| High Light: | Plastic Extruding Machine,Plastic Extruder Machine |
||
Reliable PP PE Twin Pipe Plastic Extrusion Machine Production Line Fully automatic
Quick Detail:
This line is a new type of pipe production line for PE , pp other polyolefin pipe extrusion speed , all models with advanced PLC modular intelligent control system , in order to realize the whole production line automation and real-time data recording and closed-loop control , the production line has some high yield , wide adaptation of raw materials , suatained and stable production of high quality productions such as columns a bit .
Specifications:
1. The series extruders with appropriate die- mould and auxiliary machine can directly convert thermplastic espeical PVC power into pipe,plate,sheet,film,and also provide functionof modifying and pelleting.
2. The extruders are derived by A.C motor with a thruster to steepless regulate.It is also equipped with the over-load protectionand stoppage alarming system.The screw's core and outside of barrel is cooled by circulation od oil,it includes cacuumventing and forced feeding.
Technical parameters of PP/PE Twin Pipe Extruder:
| Model/Specification | SJZ45 | SJZ55 | SJZ65 | SJZ80 | SJZ92 |
| Screw diameter(mm) | 45/90 | 55/110 | 65/132 | 80/156 | 92/188 |
| Max rotation speed(r/min) | 45 | 38 | 38 | 37 | 36 |
| Torsional moment of screw (Nm) | 3148 | 7000 | 10000 | 14000 | 32000 |
| Main motor(KW) | 15 | 22 | 37 | 55 | 110 |
| Barrel Heating Power (KW) |
9.6 | 17.5 | 23 | 33 | 73.1 |
| Production capacity (kg/h) |
70 | 150 | 250 | 400 | 750 |
| Center height(mm) | 1000 | 1000 | 1000 | 1100 | 1200 |
| Dimension (L*W*H) |
3360*1290*2127 | 3620*1050*2157 | 3715*1520*2450 | 4750*1550*2460 | 6725*1550*2814 |
Application:
HDPE pipe extruding line composed of single screw extruder and corresponding auxiliaries, can produce all kinds of small diameter HDPE plastic pipes continuously. It also can be used to produce PS, PP, HDPE plastic pipes after replacing the screw. HDPE plastic pipe is widely used for liquid conveying in agricultural, chemical industry, construction industry, etc.
Competitive advantages:
experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology
Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.
After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
