1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications

1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications
1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications 1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications 1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications

Large Image :  1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications

Product Details:
Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE & ISO9001
Model Number: SJ90/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter

1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications

Description
Raw Material: PE PPR Brand Name: Aorui
Condition: New Screw Design: Single Screw
Screw&Barrel Material: 38Cr MOAIA Automatic Grade: Fully Automatic
High Light:

plastic pipe extrusion machine

,

plastic pipe production line





1 Extruder PE PPR Water Plastic Pipe Making Machine Fully Automatic CE certifications





Quick detail



PE PPR Plastic Pipe Machine Characteristics


1. The optimum spiral structure feeding throat highly improves the output of extruder

2. Accurate temperature control system ensures materials melting performance

3. Unique screw design achieves better plasticizing and high quality products

4. Precisely designed gearbox with a high torsion guarantees stable running

5. "H" shape frame to decrease vibrating of extruder

6. Advanced PLC operation system realizes synchronization and automation






Description:



1. Features -->> plastic pipe extrusion machine
SJ series single screw extruder plastic machine mainly apply to extrude PP,PE,PET,PVC,ABS,PS,PA ect material.It adopt special gear box,and has features of low noisy ,stable running ,high carrying capacity,long service life .Equipped with different mold and auxiliary equipments,it could produce plastic pipe ,sheet ,board, granules and so on .It has features of simple process,high output ,stable extrusion pressure,and low cost.



2. Special single screw extruder for polyolefin , having high extruding velocity and effective plasticization. Separation mixing screw specialized for polyolefin. Separation designed 2-3 co-extruding die , reasonable channel , smooth outside and inside wall , and little internal stress..



3. Producing pipe limit 20-160mm , manufacture velocity up to 15m/min. May be used to produce HDPE silicon core tube , ordinary PP-R, PE ,PEX , and PE-RT pipes.







Main technical parameters



Pipe ranger(mm) 20-63 50-160 150-250 250-315 280-630
Extruder SJ65/33 SJ75/33 SJ90/33 SJ120/33 SJ150/33
Capacity(kg/h) 50-80 80-150 180-260 300-400 450-600
Total power(kw) 75 145 195 220 350
Line length 35 38 42 44 56
Control system PLC PLC PLC PLC PLC



If you want more details of our HDPE pipe machine/ HDPE pipe making machine, please let us know!







Application:



It is mainly used to produce PE water pipe, gas pipe, drain pipe and so on. This set is also suitable for the production of crosslinked PE pipes and other olefine products. Our company can provide you with detailed ingredients and complete manufacture line.







Why choose us:



1. Our company have more than 15 years experience in design and manufacturing the plastic pipe machines.



2. Our machine have exported to all over the world



3. We offer turnkry project , and our engineers availiable to go abroad to service
