Product Details:
|
| Brand Name: | Aorui | Warranty: | 1 Year |
|---|---|---|---|
| Voltage: | 380V 50HZ | Screw&Barrel Material: | 38CrMOAIA |
| Delivery Time: | 30 Days | Certificate: | CE ISO9001 |
| Condition: | New | ||
| High Light: | plastic pipe extruder machine,plastic pipe production line |
||
PVC PP PE CE Certificate Plastic Pipe Production Line , Single Screw Extruder PE Plastic Pipe Extrusion Machine
Quick detail:
1. The Large Diameter HDPE/MDPE Pipe Extrusion Line is mainly used for city main water supply and drainage and city gas transportation.
2. Pipes produced by this machine has the moderate rigidity, strength, as well as good flexibility, anti-corrosion, anti-stress split, and favorable hot melting.
Description:
1. PE Water and Gas Plastic Pipe Production Line/pe plastic pipe production line/plastic pipe aking machine is mainly designed specially for polylefin, polythylene pipe processing and suitable for PE PP PB PPR pipe high-speed extrusion.It adopts rugged compact reducer,shielding type separation screw,slot barrel,basket type extrusion die etc,which ensure the users can make high quality plastic pipe.
2. Process flow
Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder → color code extruder → mould and calibrator → vacuum forming machine → cooling tank → haul off machine → cutting machine → discharging rack
3. Equipmnet List
PVC pipe extruder machine line : consists mainly of twin conical (parallel) screws extruder, vacuum calibrating tank, haul-off unit, cutting unit, tilter, etc.The raw material is pvc powder.
Specifications:
| Model number | PPR-16/63 | PPR-63/110 | PPR-50/160 |
| pipe diameter | 16-63mm | 63-110mm | 50-160mm |
| max output | 120kg/h | 120kg/h | 200kg/h |
| production rate | 2-10m/min | 1-10m/min | 1-8m/min |
| extruder model | SJ65/33 | SJ65/33 | SJ75/33 |
| installed power | 100kw | 110kw | 150kw |
| center height | 1000mm | 1000mm | 1000mm |
| installation area | 35*3.0*2.0m | 38*3.1*2.2 m | 38*3.2*2.2m |
Application:
1, pure water, drinking water pipeline;
2, industrial water and chemical transport, emissions;
3, domestic hot and cold water pipe system;
4, beverage, drug delivery systems of production;
5, compressed air pipe;
6, other industrial, agricultural management
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
