Product Details:
|
| Payment Terms: | TT Or L/C | Temperature Control: | Omron |
|---|---|---|---|
| Frequency Control: | ABB | Motor: | Siemens |
| Automatic Grade: | Fully Automatic | Condition: | New |
| High Light: | Plastic Profile Extrusion Machine,Plastic Profile Extruder |
||
Fully Automatic PP PE PVC WPC Plastic Profile Extrusion Process For Door Making
Quick detail:
1. This machine uses the special deisgned screw and barrel , die and extrusion process to produce plastic and wood products.
2. The series of products are: One step thick plastic and wood plate extrusion machine. One step plastic profile extrusion machine , one step plastic and wood decoration plate extrusion machine , plastic and wood pelletizing machine and different kinds of plastic and wood dies.
Description:
1. Process Flow of pvc wpc board / panel production line:
Raw material+wood power+additive→mixing → granulating → conical double screw extruder → sheet extrusion mould →cooling molding die → vacuum calibration tank → belt haul-off → cutter → rack → finished product inspecting&packing
2. The production line of electrical parts are used in the world famous brand products, combined with our company for many years plate equipment manufacturing technology and experience to make it more reliable and complete. Its production product surface smooth, bright and clean, size of the error is small, with a can nail can be planed, corrosion-resistant, fire retardant, and many other advantages.
3. This pvc window profile making machine is mainly composed by twin screw extruder, vacuum calibration and forming table, haul off machine, cutter, stacker. With various moulds, it can produce PVC UPVC window door profile, PVC ceiling, PVC window sill, PVC door, PVC cable trunking and other profiles.
Technical Parameters:
| Extruder model | SJZ55/110M | SJZ65/132M | SJZ80/156M | SJZ92/188M |
| Main motor power(kw) | 22 | 37 | 55 | 110 |
| Down-stream equipment model | YF240S | YF240A YF300A | YF600 | YF900 YF1200 |
| Product width(mm) | Max240 | Max240 Max300 | Max600 | Max900 Max1200 |
| Vacuum pump(kw) | 2*5.5 | 4*5.5 | 1*7.5 2*11 | 1*7.5 2*11 |
| Water pump(kw) | 1.5 | 4 | 7.5 | 7.5 |
| Haul-off speed | 0-5 | 0-5 | 0-3 | 0-2.5 |
| Down-stream equipment power | 22 | 35 | 44 | 52 62 |
| Output(kg/h) | 70 | 120 | 180 | 400 |
Equipment warranty
1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device
