20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty

China 20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty supplier
20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty supplier 20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty supplier 20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty supplier

Large Image :  20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty

Product Details:

Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE
Model Number: SJ65

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer ’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Detailed Product Description
Condition: New Automatic Grade: Fully Automatic
Screw Design: Single Screw Voltage: 380V 50HZ
Certificate: CE ISO9001 Warranty: 1 Year
After-sales Service: Engineers Availiable To Service



20Mm Single Wall Garden Hose Plastic Pipe Extrusion Line With 1 Year Warranty

Quick detail:

1. Single wall corrugated pipe machine development by our company adopts gears to run modules and templates so as to realize water circulating cooling and air cooling of the products,which ensures high speed molding,even corrugation,smooth inner and outer pipe wall.



2. These corrugated pipes are especially used in wires conduit pipe.It is mainly for the production of raw materials to PVC,PP,PE small diameter single wall corrugated pipe.Die by the corresponding forming a homogeneous single wall corrugated bellows products.Threading pipe for wire and cable,washing machine drains,vacuum cleaners, ventilation pipe, prestressed concrete special tubes.




Description:

1. This pipe extrusion line suits to produce the polyolefin pipe as HDPE, PP,PE etc in high production speed. It is of low power consumption, high output, high automation and reliable production.



2. The Extrusion line can porduce PE PP PVC type of corrugated pipe with different extruder, the forming machine with mould block which can reduce the cost and time for changing mould block the max. forming speed is 25M/min, Product rage:16-63mm.



3. This production line is mainly used for the PE single wall corrugation producing.
This production line also can produce the PVC electrical wires protection pipes.




Specifications:

Diameter Scope

4.5-9

9-32

32-50

Main Extruder

SJ-30

SJ-45

SJ-65

L/D

30:1

30:1

30:1

Output kg/h

10

40

80

Main Motor Power kw

4

11

18.5

Corrugator Power kw

1.1

1.5

1.5

Mould Block Pairs

42

44

44

Cooling Type

Water and air cooling

Linear Speed (m/min)

6-10

8-12

8-15

Counting Type

Sensing counting

Winding Type

Automatic/Manual




Our company competitive advantages:





  • 24 hours services;
  • Overseas installation;
  • Free operation training and technology formula transfer;
  • Old machine update;
  • Spare parts and maintenance with reasonable cost price.
