Product Details:

Place of Origin: ShanDong China
Brand Name: AORUI
Certification: CE UL CSA ISO9001
Model Number: SJSZ65/132

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per quarter
Contact Now
Detailed Product Description
Brand Name: Aorui Power: 37kw
Type Of Extruder: Twin Screw Voltage: 380V 50HZ
Screw&Barrel Material: 38Cr MOAIA Warranty: 1 Year
Original: Shandong Condition: New

Wood Plastic Profile Machine / WPC PVC Wood Profile Making Machine Extrusion Production Line





Quick detail:



1. PVC or WPC Crust Foamed Board Production Line adopts international technology, use PE, PP, PVC, PS or other plastics compounding with nature fiber powder as the raw material,employs high efficiency conical twin screw extruder, which can produce recyclable WPC board with such advantages as environment friendly, corrosion-resistance, damp-proof, moth-proof, distortion resistance, and can be processed under the same processing conditions as wood products.





2. The WPC products are popularly used as the building board, partition wall aboard, plank on storage rack and furniture board, etc.









Description:



1. For PVC window profile, equipped with correspondent co-extruder, the rubber seal or the surface color can be co-extruded on line. From the material feeding until the stacking, it is fully automatic, which also pursues the characteristics of good plasticization, low power consumption and cost effective.



2. The product has the following advantages:
*Wood-plastic composite materials instead of full-wood products, protecting forest resources.
*Wood-plastic composites can use the stalks of plants, reducing environmental pollution
*Wood-plastic composite material to eliminate white pollution, cleaning up the natural environment



3. The production line of products can be used for the production of building templates, building blocks toys with plates, trays, boxes, pallets and other packaging equipment; The end of plank, sleepers and other storage supplies, outdoor flooring, railing, outdoor chairs, garden supplies; Outdoor flooring, sun rooms, signage, flow box, stadium chairs, and other load-bearing beam.









Specifications:



Name of equipments Spec. /Model TH210 TH240 TH500 TH800
Extruder Extruder model TSZ51/105 TSZ65/132 TSZ80/156 TSZ92/188
Dimension(m) 3.3*1.45*2.1 3.45*1.45*2.25 5*1.54*2.28 6.2*1.55*2.7
Capacity(kg/h) 50-150 80-250 100-350 200-600
Installed paower(KW) 25 64 115 168
Sizing table Dimension(m) 4.2*1*1.1 5.8*1. *1.1 6.5*1.5*1.1 6.5*1.5*1.1
Installed paower(KW) 18 24 30 43
Hauling and cutting machine Dimension(m) 5.8*1.1*1.7 5.8*1.1*1.7 3.1*1.3*1.7 2.2*1.45*1.8 3.55*1.85*1.6 2.5*1.8*1.6
Hauling speed (m/min) 0-4 0-4 0-3 0-2
Hauling force (N) 30000 30000 35000 50000
Max cutting area and width (mm) 240*65 240*65 500*80 800*80
Installed power (KW) 6 6 8 8
Stacker Stacking length(mm) 6 6 6 6









Company advantages:



experience:Our company have more than 15 years’ experience in designing and manufacturing the extrusion equipment; the core technology and equipment are communicating and docking with the advanced European plastics processing technology

Market: Our products have been sold to all over the China and exported to countries all over the world, such as Russia, Ukraine, Armenia, Azerbaijan, Uzbekistan, Kazakhstan, Italy, Romania, Australia, Turkey, Iran, Pakistan, India, Bangladesh, Indonesia, Japan, Vietnam, Mexico, Venezuela, Brazil, Peru, South Africa, Egypt, Tunisia, and so on.

After Sales Service: We offer turnkey project,technicians will be sent to buyer's factory for installation and commissioning of the equipmnet and training of workers;all you maintenance requirements to equipment will be replied within 24 hours.
