Fully Automatic 50HZ Plastic Profile Extrusion Line , PVC PP PE Profile Extruder

Brand Name:	AORUI
Model Number:	SJSZ65/132
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	10 sets per quarter

Detail Information

Product Description

Detail Information

Place of Origin:

ShanDong China

Certification:

CE UL CSA ISO9001

Plastic Processed:

PP PE

Place Of Original:

Shandong , China

Voltage:

380V 50HZ

Feature:

Easy To Operation

Experience:

More 15 Years

Automatic Grade:

Fully Automatic

Packaging Details:

Fumigation wood, film,pallet,etc or according to customer’s requirement.

Supply Ability:

10 sets per quarter

Highlight:

Plastic Profile Extrusion Machine

Plastic Profile Extruder

Product Description

Fully Automatic 50HZ Plastic Profile Extrusion Line , PVC PP PE Profile Extruder

Quick detail:

1. The screw barrel special design, mould and extrusion machine production process for production of wood plastic products.

2. The production line can produce PE, PP or PVC plastic profile products, durable products, the advantages of plastic products and wood products, plastic products.

Description:

1. YF Series PVC profiles extrusion line is mainly used in PVC plastic steel doors and windows profile,window panels, perforated pipe threading and foam profile extrusion products. The production line according to the different requirements of customers and cross-sectional shape of the mold, you can choose the most suitable twin-screw extruder , and equipped with the appropriate vacuum form-ing . Cuttting and other auxiliary traction.

2. This kind of small extruder can be used in different kinds of area such as:

1. ABS filament extruder.

2. PLA filament extruder.

3. Small diameter PVC/PA/PC tube extruder.

4. Window edge band extruder.

5. Soft PVC profile extuder.

6. Plastic pellets making.

7. Rattan making.

Technical Parameters:

Items	YF180	YF240	YF300	YF600	YF900
Max.width of board(mm)	180	240	300	600	900
Extruder Model	SJZ55/110	SJZ65/132		SJZ80/156	SJZ92/188
Mian motor power(KW)	22	37		55	110
Drawing height(mm)	150	150	150	150	150
Drawing speed(KN)	20	20	20	30	40
Drawing speed(m/s)	0-5	0-5	0-5	0-3	0-2.5
Auxiliary equipment sum power(kw)	35	35	30	30	40
Cooling water consume(m 3 /h)	6	6	6	9	12
Compression air(Mpa)	0.6	0.6	0.6	0.6	0.6

Equipment warranty:

1. About the equipment, Middle tech promised the good quality of 12 month.
2. during the warranty, no purposely and artificially damage change the damaged part, we will free
maintenance and technical services.
3. Over 12 months, Buyer's needs to pay the producing cost of the worn part, and life-long supply the part of equipment and freely device.
