Fully Automatic Strapping Band Machine PP PET Packing Belt Production

Fully Automatic Strapping Band Machine PP PET Packing Belt Production

Brand Name: AORUI
Model Number: PET75
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Place Of Original:
Shandong , China
Condition:
New
Model Number:
PET 75
Trade Mark:
Aorui
After-sales Service:
Engineers Anailiable To Service
Port:
Qingdao
Automatic Grade:
Fully Automatic
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

Strapping Band Making Machine

,

Strap Making Machine

Product Description



Fully Automatic Strapping Band Machine PP PET Packing Belt Production







Quick detail:



Features of PET Strap Making Machine

1. Using the recycling bottle slices as raw materials by making them melt directly,
which reduces the course of raw material-making

2. With the multi-purpose machine, it can produce PET straps in different specifications
directly and doesn't need to change the mould head

3. The products has the same transparency as made from new polyester slices, but
the tensile strength and shock resistance are stronger









Description:



1.  The YZJPet intelligent light weight strapping band unit produced by our company through repeating research and development, based on the reinforced strapping band unit, is specially used for the top-grade light weight products with good quality, light gram weight and well rigidity. Its high-speed low-temperature stretching technology and optimized structure may reduce energy consumption to the maximum extent, simplify operating procedure and realize digital displayed accurate control.



2. The unit has advantages of energy saving, great extrusion pressure, optimal embossing effect, high output, good formation, convenient maintenance, simple operation, safety and reliability. The single-band unit is an ideal device that is used to manufacture top-grade light weight strapping band. This unit is applicable to PP fresh material and used for producing light weight strapping band.



3. PP packing straps extrusion machine features:
3.1. High and stable production efficiency
3.2. Good quality machine with competitive price

3.3. can equip Siemens PLC control, or designed according to customer's requirements









Technological parameter:



Extruder SJ-65/28 SJ-80/28 SJ-90/28
Drive Motor 22kw 30kw 55kw
Two-station Winder 80-120m/min,adjustable
Strap Size Width:5mm-20mm Width:10mm-25mm Width:20mm-35mm
Thickness:0.36mm-1.0mm Thickness:0.5mm-1.3mm Thickness:0.5mm-1.8mm
Installed Capacity About 40kw about 60kw about80kw
Line Dimension 26m×2m×2.2m (L×W×H) 26m×3m×3m (L×W×H) 26m×5m×3.5m (L×W×H)









Competitive Advantage:



  • 24 hours services;
  • Overseas installation;
  • Free operation training and technology formula transfer;
  • Old machine update;
  • Spare parts and maintenance with reasonable cost price.
