Product Details:
|
| Application: | Pipe | Automatic Grade: | Fully Automatic |
|---|---|---|---|
| Voltage: | 380V 50HZ | Inverter: | ABB |
| Motor: | Siemens | Certificate: | CE ISO9001 |
| Temperature Controller: | Omron | ||
| High Light: | plastic pipe extruder machine,plastic pipe extrusion machine |
||
Plastic Gas and Water Supply PE Pipe Extrusion Line / Single Screw Plastic Pipe Extruder Machine
Quick detail:
1. SJ series single screw extruder plastic machine mainly apply to extrude PP,PE,PET,PVC,ABS,PS,PA ect material.It adopt special gear box,and has features of low noisy ,stable running ,high carrying capacity,long service life .
2. Equipped with different mold and auxiliary equipments,it could produce plastic pipe ,sheet ,board, granules and so on .It has features of simple process,high output ,stable extrusion pressure,and low cost.
3. PP Pipe Production Line Process flow -->> single screw extruder plastic machine
PP+ additive → mixing → spring feeding → single screw extruder → mould and calibrator → vacuum forming machine → haul off machine → cutting machine → stacker
Description:
1. Product Information
PE pipe extrusion line is mainly used for producting plastic pipe for agriculture water supply & sewage, for building industries water supply & sewage, for cable and wire laying.
2. The line consist of single screw extruder, vacuum tank, cooling tank, haul-off unit, cutter and storage table.Single extruder and haul-off unit adopt international brand AC inverter speed control, Vacuum pump and haul-off motor use premium bgrand.Haul-off can be equipped with 2/4/6/8/10/12 belt according to the pipe sizes. Cutter can be swarfless, saw blade, or planetary cutting type.
3. The line featured by stable performance and high efficiency. This line can also produce PE PP inner sprial pipe, hollow pipe, and foaming pipe bychaning the configruation.The line is fully Automatic control, easy operation, stable performance, reaching international leading level.
Specifications:
| Pipe Diameter(mm) | 16-63 | 32-125 | 75-250 | 110-450 | 315-630 | 315-800 | |
| Extruder | 45/33 | 75/33 | 60 | 60/38 75/33 |
75/38 90/33 |
90/38 120/33 |
105/38 150/33 |
| Strand | single strand | double strand | single strand | single strand | single strand | single strand | single strand |
| Downstream equipment | LG63 | SLG63 | LG125 | LG250 | LG450 | ||
| Total power(KB) | 70 | 125 | 150 | 230 | 380 | 550 | 800 |
Competitive Advantage:
Technical and after-sales service:
The supplier the following technical and after-sales service commitment
A) Provide on-site installation guide;
B) Responsible for the commissioning of equipment;
C) Responsible for the buyer's personnel mount guard before the operation and maintenance training;
D) One year free warranty (due to the buyer's improper operation caused by damage charge costs), and ensure the supply of spare parts for a long time, only receive the cost.
E) Provide technical advisory services for a long time
