Product Details:
|
| Raw Material: | PE | Power: | 37kw |
|---|---|---|---|
| Type Of Extruder: | Single Screw Extruder | Voltage: | 380V 50HZ |
| Screw&Barrel Material: | 38Cr MOAIA | Delivery Time: | 30 Days |
| Warranty: | 1 Year | ||
| High Light: | plastic pipe extruder machine,plastic pipe extrusion machine |
||
Single Screw Plastic Pipe Extrusion Line , PE Single Wall Corrugated Plastic Tube Extruder
Plastic Corrugated Pipe Extrusion Line , PE Single Wall Corrugated Tube Extrusion Machinery
Quick detail:
1. It is developed by our company based on absorbing advanced German technology. It has advantages, such as, reasonable structure, stable operation, fast forming speed.
2. PE Single wall corrugated pipe production line , adopt high speed single screw extruder. Adopt high speed screw, slotting barrel, corrugated pipe inner and outer wall is separately provided by two extruders.
3. High strength corrugated pipe forming systerm ,can assure the high capacity when production.
Description:
1. HDPE plastic corrugated pipes are used all over the world as a standard in efficient sewage and drainage systems since the last 40 years., from ALOM, is a pipe of the finest quality for non pressure underground sewerage, drainage and cross drainage (pipe culvert) purpose.
2. It consists of automatic feeding system/single screw extruder/die head/forming machine /winder. It is mainly produce PE/PP/PVC single corrugated pipe. The PE/PP/PVC single corrugated pipe is mainly used in the golf course, playgrounds as light load of drainage, floods; Interior decoration cable casing; Automotive wire casing; The washing machine, air conditioner drain; Prestressed concrete special pipe, etc.
3. The machine is mainly used in extruding soft and hard thermoplastics, such as polyviyl chloride(PVC),polyethylene and others. It is used with relevant auxiliary machine (including shaping machine head)to produce several kinds of plastic products, for example: film, pipe, rod, plate, thread, cable insulating layer, hollow product. It is also used of prilling.
Specifications:
| Pipe Diameter(mm) | 16-63 | 32-125 | 75-250 | 110-450 | 315-630 | 315-800 | |
| Extruder | 45/33 | 75/33 | 60 | 60/38 75/33 |
75/38 90/33 |
90/38 120/33 |
105/38 150/33 |
| Strand | single strand | double strand | single strand | single strand | single strand | single strand | single strand |
| Downstream equipment | LG63 | SLG63 | LG125 | LG250 | LG450 | ||
| Total power(KB) | 70 | 125 | 150 | 230 | 380 | 550 | 800 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
