Strapping Band Machine
Created with Pixso.

Single Screw PP PET Strapping Band Making Machinery , PP Strap Extrusion Machinery For Packing

Single Screw PP PET Strapping Band Making Machinery , PP Strap Extrusion Machinery For Packing

Brand Name: AORUI
Model Number: PET90
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Model Number:
PET 90
Port:
Qingdao
Temperature Controoler:
Omron
Screw Number:
One
Frequency Control:
ABB
Motor:
Siemens
Certificate:
CE ISO9001
Payment Terms:
TT Or L/C
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

Strapping Band Making Machine

,

Strap Making Machine

Product Description

Single Screw PP PET Strapping Band Making Machinery , PP Strap Extrusion Machinery For Packing





Quick detail:



1. PP Strapping Roll Product Description:
Polypropylene(PP) strap is an economical material designed for light to medium duty unitizing, palletizing and bundling etc. Compared with other straps, PP strap is the "Beauty", as it can be made in different colors with good transparence. It can be recycled for it is an environment protective strapping material.



2. Our advantages:

product strap roll since 1995
100% virgin(new) PP materials;
Different material for option(Virgin, Semi-Virgin, Recycle Material)
Accept customized to product size and color;
Accept sample order with MOQ;
Accept printing words or make customer's logo;









Description:



1. This plastic mahcine PP strap band product for packaging. This line is comparatively low cost. The line speed is 80m/min. The width and thickness of the strap band is adjustable.



2. PP Bale Strap Machine is a renewed and improved design, and is special for producing the polypropylene packing strip.
The whole machine includes the extruder, mould, cooling tank, haul-off device, embossing device, winder and electrics controlling part.



3. The screw is with the special design and treatment and can ensure the excellent strip quality.
The whole equipment has the advantages of high capacity, excellent plasticization, strong processing adaptation, easy operation and overhaul.Every technical index reaches the international developed level











Technological parameter:



Model SJ-65 SJ-75 SJ-90
Extruder SJ-65/30 SJ-75/33 SJ-90/33
Productivity 60-100kg/h 80-120kg/h 120-150kg/h
Drive Motor 22kw 30kw 55kw
Two-station Winder 60-120m/min,adjustable
Strap Size Width:5mm-20mm Width:10mm-25mm Width:20mm-35mm
Thickness:0.36mm-1.0mm Thickness:0.5mm-1.3mm Thickness:0.5mm-1.8mm
Installed Capacity about80kw about 90kw about110kw
Line Dimension 30m×2m×2.2m (L×W×H) 30m×3m×4.5m (L×W×H) 30m×5m×6m (L×W×











Technical and after-sales service:


The supplier the following technical and after-sales service commitment
A) Provide on-site installation guide;
B) Responsible for the commissioning of equipment;
C) Responsible for the buyer's personnel mount guard before the operation and maintenance training;
D) One year free warranty (due to the buyer's improper operation caused by damage charge costs), and ensure the supply of spare parts for a long time, only receive the cost.
E) Provide technical advisory services for a long time
