Plastic Sheet Extrusion Line
Created with Pixso.

Recycled PET Plastic Sheet Extrusion Line Co-Extrusion For APET PETG

Recycled PET Plastic Sheet Extrusion Line Co-Extrusion For APET PETG

Brand Name: AORUI
MOQ: One set
Price: Negotiable
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month
Detail Information
Place of Origin:
China
Certification:
CE UL CSA
Plastic Processed:
PET
Voltage:
380V/50HZ
Capacity:
100-450kg/h
Thickness:
0.18-2mm
Type:
Plastic Production Line, Plastic Extrusion Line
Screw Design:
Single Screw
Automatic Grade:
Full Automatic
Application:
Sheet
Packaging Details:
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Supply Ability:
10 Sets per month
Highlight:

plastic sheet production line

,

plastic sheet extruder machine

Product Description



Recycled PET Plastic Sheet Extrusion Line Co-Extrusion For APET PETG



Quick detail:



  Material : PET

  Voltage: 380v/50hz

  Screw design: single screw

  Capacity: 100-450kg/h

  Product type : sheet

  width of sheet: 1200mm

  thickness of sheet : 0.18-2mm

  speed of production line: 5-25m/min

  condition : new

  certification: CE UL CSA

  warranty: 1 year





Description:



1.suitable for 100% PET recycled material,thickness:0.2-2mm,max output 600-700kg/h,also can be custom-

made,according to requirement.



2.This machine unit adopts the specially-designed single or double screw extruder, according to

requirement.Also,it can choose co-extrusion technology for APET,PETG,etc.



3.Double column and double station screen,having the feature of good exhaust and cleaness.



4.on line silicone oil, anti-static device,imported transducer for speed adjusting, and imported RKC

temperature control instrument, featuring wide adjusting scope, high temperature control precision, and

convenient and reliable operation.



5.The auxiliary machine comprises vacuum shaping platform, tractor, cutter, and loading rack. The

equipment of large forced refrigeration device ensures the shaping effect of door plates. Crawl type tractor

adopts imported reducer motor and transducer and it’s distinguished by reasonable structure, large

traction force, and stable traction. The cutter is reliable and correct in operation and high in cutting

precision. The loading rack, outfitted with movable loading trolley and special rubber protection layer,

doesn’t damage any materials and is convenient for use.



6.The auxiliary machine unit adopts PLC control or domestic famous control system, reliable and stable.

 Recycled PET Plastic Sheet Extrusion Line Co-Extrusion For APET PETG 0



Applications:



Vacuum forming: food packager; toy box; stationery case; hardware packing

Obstruct packing: for electric components packing

Normal application: folded forming; collar lining; decoration material; file folder; document cover;

Special application: medical instrument;medicine packing; industrial anti-sepsis; roast tray.

Recycled PET Plastic Sheet Extrusion Line Co-Extrusion For APET PETG 1



Specifications:



Model

Extruder

Motor Power

(kw)

Width(mm)

Thickness(mm)

Line Speed(m/min)

Output

(kg/h)

SSP-PET120

SJ120×30

132

500-1200

0.15-2

5-25

450

SSP-PET150

SJ150×30

185

800-2200

0.15-2

5-18

650





Competitive Advantage:



  1. CE and UL
  2.  rich ience engineer
  3. competitive price
  4. good after service
