HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder

HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder
HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder

Large Image :  HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder

Product Details:
Place of Origin: China
Brand Name: AORUI
Certification: CE UL CSA
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 Sets per month

HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder

Description
Feature: Good Quality,high Output Process: Extrusion
Product Type: Sheet Material: 100% Recycled
Type: Sheet Plastic Production Line Screw Design: Single Screw
Application: Package,protection,etc Certificate: CE,ISO9001
Market: All Over The World
High Light:

plastic sheet extrusion machine

,

plastic sheet extruder machine

HIPS Cups Plastic Sheet Extruder Machine Multi-layer for Construction Extruder






QUICK DETAIL :


1.Available material:PP,HIPS,GPPS,PE
2.Stationery Plastic Sheet Extruder
3.Certification:CE,CNAS,ISO


Description:


PP/PE/PC/PS/ABS/PMMA/HIPS plastic plate production line can continuously produce mono-layer or multi-layer PP/PE/ABS/PMMA/PC/PS/HIPS plate and sheet with the width less than 3000mm and thickness of 0.25-30mm.



The products are widely used in the fields of refrigerator, air conditioner, auto, advertisement, and construction, environmental protection, etc.


Extruder:

Appropriate single-screw extruder (exhaust or not) should be chosen on the basis of different materials. Specially designed screw and advanced temperature controlling system ensure the good plasticization, high output and stable extruding.



Three-roller calendaring machine:

 Adopts vertical three-roller calendering machine, equipped with roller temperature controlling device, the space of three roller can be adjusted manually and automatically, which has the function of emergency cut off ensure safety.



Bracket of cooling roller:

  Equipped with corresponding guide roller, the cooling effect is better. In addition, the edge-shearing and parting off device is equipped which can guarantee fixed width of plates and quality of edge.



Landscape orientation cutting machine:

  With cylinder clamping, moving cutting, speed frequency regulating to protect the cutting speed synchronize with plate making speed. Cutting with alloy saw blade, equipped with dust absorption device





FEATURES:



1. Good mould ability due to the large L/D ratio of the screw in the extrusion unit
2. Advanced hydraulic pressure, high speed net changing fitting without stopping the machine
3. Convenient operation, excellent function
4. Improves production efficiency
5. The mould of heat inside is featured by easy mould adjusting, equal sheet thickness, constant flowing speed, high hot utilization and energy saving
6. Sheet cutting machines work automatically, such as cutting sheets with settled length, counting number by adopting the micro-computer and laser-pressed control
7. Producing PP, HIPS, GPPS, PE stationery sheet and other packing material.



Applications:


(1) the main parts, such as screw ,barrel, adopt superior 38CrMoAlA material, which is featured by high hardness,anticorrosive advantages.
(2) The special designed screw adopts big L/D Ratio to ensure the good plasticizing,stable extrusion and high output.
(3) Screen extruder:it is controlled by motor and its operation is very easy (we can also adopt hydraulic style fast screen exchange with double filters according to customers demand.







Specifications:



  Model

Unit

TYJB-75

TYJB-90

TYJB-110

  Material applied

PP,PS,PE

  Width of sheet

mm

≤600

≤750

≤1100

  Thickness of sheet

mm

0.2-1.6

0.2-2.0

0.2-2.0

  Extrusion capacity

kg/h

60-100

100-150

150-200

  Diameter of screw

mm

75

90

105

  Installed capacity

kw

75

90

120



Competitive Advantage:

1.material: grains
2.Mould:hot work steel,5CrNiMo.
3.CE.
