Product Details:
|
| Product Type: | Sheet | Feature: | High Output |
|---|---|---|---|
| Voltage: | 380v/50hz | Size: | According To Customer's Requirement |
| Type: | Plastic Production Line, Plastic Extrusion Line | Screw Design: | Single Screw |
| Field: | Europe,africa,north America,etc | Application: | Sheet |
| High Light: | plastic sheet extrusion machine,plastic sheet extruder machine |
||
PP / PE Plastic Sheet Extrusion Line , Box / Cup Plastic Sheet Extrusion Machine
QUICK DETAIL :
1. Mainly used to produce PP, HIPS, GPPS, PE sheet and other packing material
2. Big ratio of length and diameter for the screw of the extrusion machine
3. Good forming effect, equal thickness of sheet and same running speed
4. Advanced hydraulic pressure, high speed net changing fittings without stopping the machine
5. Convenient operation and excellent function
6. Improve the production efficiency
Description:
This unit is suitable for producing PP, PE, HIPS, ABS etc. plastic sheet material. It can be used to produce all kinds of heat-forming products, such as the cold drink cup, fruit jelly cup, yogurt cup, ice cream cup, fast-food box, instant noodles bowl etc.It also can be used to produce the package products for the medicine, light industry, hardware, toy plastic etc. fields.
Main technical parameter
|
Main Machine Provided |
Single Screw Extruder |
|
Valid Screw Length(L/D) |
30 : 1 |
|
Screw Rotating Speed(r/min) |
60 - 90 |
|
Main Moto Power |
132 |
|
Capacity (Q>= kg/h) |
300 |
|
Width of Pressure x Diameter (mm) |
1800 x 490 |
|
Rotational Speed of Pressure (r/min) |
0.15 – 3 |
|
Drawing Speed (r/min) |
0.15 – 3 |
|
Drawing Power (kw) |
4 |
|
Cutting Power (kw) |
4 |
|
Dverall Dimension of The Line (LxWxH) |
45 x 3.5 x 4.25
|
Applications:
(1) PE and PP sheet production line is mainly used in the products of PE or PP thicker plastic plates(sheets)Plates thickness:2-40mm ,Plates width:750-1800mm.
(2) About all parts of the equipment is adopted known brand products. Our company had experiences and technologies made plastic plates(sheets),so it has the easy operation, and the products made by us has characteristics of low cost. Clean outside, little error, antiseptic, insulation and other merits.
(3) Whats more , if you make a better change for it. It can be made LDPE or HDPE plastic foaming plates(sheets).
Specifications:
|
Model |
Unit |
TYJB-75 |
TYJB-90 |
TYJB-110 |
|
Material applied |
PP,PS,PE |
|||
|
Width of sheet |
mm |
≤600 |
≤750 |
≤1100 |
|
Thickness of sheet |
mm |
0.2-1.6 |
0.2-2.0 |
0.2-2.0 |
|
Extrusion capacity |
kg/h |
60-100 |
100-150 |
150-200 |
|
Diameter of screw |
mm |
75 |
90 |
105 |
|
Installed capacity |
kw |
75 |
90 |
120 |
Competitive Advantage:
1. manufacturer of plastic machinery
2. Qingdao port and lower cost
3. high quality with high reputation
4. rich expreience
