Product Details:
|
| Place Of Origin: | Shandong, China (Mainland) | Type: | PET Granule Machine |
|---|---|---|---|
| Output: | 1000kg | Cetificate: | CE,ISO9001 |
| Screw Type: | Double Screw | Feature: | High Output |
| Automatic Grade: | Automatic | ||
| High Light: | Plastic Recycling Machine,Plastic Pelletizing Machine |
||
PET Double Screw Recycle Plastic Granules Machine , Plastic Granule Making Machine
QUICK DETAIL:
1 . screw material:38CrMoALA
2 . low noise, stable performance and easy operation
3 . After-sales Service Provided : Engineers available to service machinery overseas
Description:
twin screw extruder adopts building block type screw,dual alloy barrel,screw configuration,barrel structure,L/D,feeding port and exhast port quantity,changing screen and cutting type can be all adjust according to material system and process requirement,optimizing configuration.The line mainly used for PET bottle pelletizing and PS,ABS,PA other material modified pelletizing
This machine is used to extrude plastic cleaned by high temperature.The extrusion line can be consisted by such accessory machine: main motor, the gear box, the distribution box, the barrel and screw, the dies,vacuum calibration tank. Main Motor is mainly to supply the power. The Gear box transfers the motor to power.The distribution box enlarges the strength of the power and realizes uniformity.Double screws can make low viscosity index consume of raw material and improve production.It also has a Cooling tank making the heat of screw be appropriate.
We use plug board type to change nets and keep machine working.The mould is made by 40Cr nitridation.The pressure sensor prompts to change the nets.There also can install a hydraulic equipment to change the nets more quickly.
Applications:
1 . It has force feeder to press the light film into the screw,easy to operate and make sure the capacity.
2 . With Non-stop hydraulic screen exchanger,you can exchange the screen when the machine is running
3 . With double stage single screw extruders,the plastic can be plasticized totally,keep the capacity steady and without air hole in the final granules.
Specifications:
|
Item |
Description |
|
1 |
Inspection belt conveyer with iron absorber |
|
2 |
Belt conveyer |
|
3 |
Label removing machine |
|
4 |
Belt conveyer |
|
5 |
Crusher |
|
6 |
Screw conveyer |
|
7 |
Flotation tank |
|
8 |
Screw conveyer |
|
9 |
Hot washing tank ( with electric heating ) |
|
10 |
Screw conveyer |
|
11 |
High speed Scrubbing washing unit |
|
12 |
Flotation rinsing unit 01 |
|
13 |
Flotation rinsing unit 02 |
|
14 |
Centrifugal dryer |
|
15 |
Vibrosieve ( powder dust separator ) |
|
16 |
Electric heating drying unit |
|
17 |
Small paper and label separator |
|
18 |
Silo |
|
19 |
Electric control cabinet |
Competitive Advantage:
1 . T/T & L/C are both accepted by our factory.
2 . Our warranty is a year including 12months acount to machinery operated normally.
3 . Our service, we can arrange you to come to our factory to test the machinery and we will provide the visiting services after order.
