Sewage Drainage Plastic Pipe Extrusion Line , Plastic Pipe Manufacturing Machine

Brand Name:	AORUI
Model Number:	SJSZ65
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	10 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShanDong China

Certification:

CE UL CSA

After-sales Service Provided:

Engineers Available To Service

Plastic Processed:

PVC

Certification:

CE,BV,ISO9001

Dimension(L*W*H):

30M*2.5M*4M

Screw Design:

Double Screw

Application:

Pipe

Place Of Origin:

Shandong, China (Mainland)

Packaging Details:

Fumigationwood, film,pallet,etc or according to customer’s requirement.

Supply Ability:

10 sets per month

Highlight:

plastic pipe extrusion machine

plastic pipe production line

Product Description

Sewage Drainage Application PVC Pipe Extrusion Machine PVC pipe extrusion machine

Quick detail:

Pipe Material : PVC

Screw design : double screw

mould: change molds to produce different pipe products.

Description:

The working process of PVC conduit pipe making machine:

It is mainly used in producing various diameters and wall-thickness of PVC pipes for aggriculture and

constructional plumbing cable laying etc.

Our PVC pipe extrusion machine has features of low consumption, high output, stable running etc.

The standard PVC pipe extrusion machine include: material charger, SJZ series conic twin screw

extruder, mould, vacuum calibration tank, spray cooling tank(for big pipe), haul-off, cutter, stacker.

Clients also can choose double/four PVC pipe extrusion line to make small size PVC pipes.

The main electrics for PVC pipe extrusion machine only adopt Siemens motor, siemens contactor,

ABB inverter, Omron temperature meter.

All of our PVC pipe extrusion machine will be tested before delivery, and we will invite our cients to

come and testing the whole line with us together.

Specifications:

Main Technical Parameters
MODEL	PVCG-110	PVCG-160	PVCG-250	PVCG-315	PVCG-400	PVCG-630
MATCHED EXTRUDER	SJZ51/105	SJZ65/132	SJZ65/132	SJZ80/156	SJZ80/156	SJG92/188
OD RANGE(mm)	50-110	50-160	75- 250	110-315	200-400	315-630
LENGTH OF VACUUM CALIBRATOR TANK(mm)	6000	6000	6000	6000	6000	6000
HAUL SPEED(m/min)	0.6-6	0.5-5	0.4-4	0.3-3	0.2-2.5	0.2-1.5
INSTALLED POWER(kw)	67	85	95	125	135	255
TOTAL LENGTH9(mm)	17000	18000	20000	20500	28000	30000

Applications:

1. Capacity: Conical twin-screw extruder, suitable for process PVC powder with high capacity, max 600KG/H

2. Diameter: our company succeed in designing and producing the biggest conical twin-screw extruder in the world.

3. Auxiliary machine closely meet customer specifications. Nice appearance, automatic control and stable running performance.

Competitive Advantage:

1 . long working time

2 . high output
3 . energy saving
